JBL STUDIO Series - Mechanical Parts List

S412P MECHANICAL PARTS LIST (See following page)
1 Cabinet S412P (Not for Sale)
2 Grille 335417-002
3 Low Frequency Transducer 12” PolyPlas cone shielded
DC Resistance 5.6 ohms ±10%
335151-001
4 Mid-Bass Transducer 6.5” PolyPlas cone shielded
DC Resistance 4.8 ohms ±10%
335148-001
5 Mid Frequency Transducer 4” Polyplas shielded
DC Resistance 4.3 ohms ±10%
335439-001
6 High Frequency Transducer 1” Titanium Dome shielded
DC Resistance 3.4 ohms ±10%
335663-001
7 Crossover Network 335678-001
8 Faceplate 335157-001
9 Amp assembly 335679-001
10 Grille retainers (6) 333249-001
11 Faceplate gasket 335667-001
12 Port Tube 335155-001
13 Flower pot 334072-001
14 Foot (4) 335429-001
15 Bump-on pads for feet (4) 330104-001
16 Terminal cup 335471-002
S1
Screw (tweeter) (2)
#6 x .375” PPH 903401-006
S2 Screw (faceplate) (6) #6 x .75” HXS-HD 908302-012
S3 Screw (midrange) (4) #6 x .75” PPH 61867
S4 Screw (mid-bass) (6) #8 x .75 HXS-HD 903802-012
S5 Screw (woofer) (8) #8 x .75 HXS-HD 903802-012
S6 Screw (terminal cup) (4) #6 x .75” PPH 63563
S7 Screw (network) (4) #6 x .75” PPH 63563
S8 Screw (feet) (4) #8 x 1” HXS-HD BLK 72216
