JBL STUDIO Series - Electrical Parts List

Part Number
Description
Q'ty
Designator
Resistors
11012100j52
resistor 10 ohms 1/2W,+/-5% 52mm
1
R139
11012182j52
resistor 1.8K 1/2W,+/-5% CF 52mm
1
R152
11012221j52
resistor 220 ohms,1/2W,+/-5% CF 52mm
2
R160,163
11014101j26
resisor100 ohms 1/4W,+/-5% CF
1
R133
11014102j26
resistor 1K 1/4W,+/-5% CF
4
R135,170,171,244
11014103j26
resistor 10K 1/4W,+/-5% CF
3
R105,116,205
11014104j26
resistor 100K 1/4W, +/-5% CF
2
R144,145
11010105j26
resistor 1M 1/4W, +/-5% CF
1
R159
11014151j26
resistor 150 ohms, 1/4W CF
2
R126,127
11014152j26
resistor 1.5K 1/4W,+/-5% CF
2
R113,134
11014153j26
resistor 15k 1/4W,+/-5% CF
3
R121,166,168
11014182j26
resistor 1.8k 1/4W,+/-5% CF 27mm
1
R167
11014220j26
resistor 22 ohms 1/4W,+/-5% CF 28mm
2
R128,129
11014222j26
resistor 2.2k 1/4W,+/-5% CF 27mm
3
R161,164,173
11014223j26
resistor 22k 1/4W,+/-5% CF 28mm
5
R103,104,115,141,143
11014271j26
resistor 270 ohms 1/4W,+/-5% CF 28mm
2
R162,165
11014332j26
resistor 3.3K 1/4W,+/-5% CF
3
R117,118,136
11014333j26
resistor 33K 1/4W,+/-5% CF
1
R101
11014392j26
resistor 3.9K 1/4W,+/-5% CF
2
R122,123
11014470j26
resistor 47 ohms 1/4W,+/-5% CF
2
R124,125
11014471j26
resistor 47 ohms 1/4W,+/-5% CF
1
R147
11014472j26
resistor 4.7K 1/4W,+/-5% CF
5
R140,142,151,156,157
11014473j26
resistor 47K 1/4W,+/-5% CF
4
R138,149,150,158
11014510j26
resistor 51 ohms 1/4W,+/-5% CF
1
R132
11014512j26
resistor 5.1K 1/4W,+/-5% CF
1
R120
11014562j26
resistor 5.6K 1/4W,+/-5% CF
1
R155
11014682j26
resistor 6.8K 1/4W,+/-5% CF
3
R119,146,153
11014683j26
resistor 68K 1/4W,+/-5% CF
3
R114,169,172
11014911j26
resistor 910 ohms 1/4W,+/-5% CF
1
R154
11016100j26
resistor 10 ohms 1/6W,+/-5% CF
1
R224
11016102j26
resistor 1K 1/6W,+/-5% CF
1
R236
11016103j26
resistor 10K 1/6W,+/-5% CF
9
R206,210,216,219,222,239,246,247,248
11016104j26
resistor 100K 1/6W,+/-5% CF
4
R203,204,227,228
11016105j26
resistor 1M 1/6W,+/-5% CF
1
R242
11016151j26
resistor 150 ohms 1/6W,+/-5% CF
1
R235
11016154j26
resistor 150K 1/6W,+/-5% CF
1
R234
11016183j26
resistor 18K 1/6W,+/-5% CF
1
R240
11016221j26
resistor 220 ohms 1/6W,+/-5% CF
2
R229,230
11016223j26
resistor 22K 1/6W,+/-5% CF
3
R237,243,245
11016224j26
resistor 220K 1/6W,+/-5% CF
1
R215
11016271j26
resistor 270 ohms 1/6W,+/-5% CF
1
R226
11016275j26
resistor 2.7M 1/6W,+/-5% CF
1
R238
11016332j26
resistor 3.3K 1/6W,+/-5% CF
2
R223,225
11016333j26
resistor 33K 1/6W,+/-5% CF
1
R137
11016363j26
resistor 36K 1/6W,+/-5% CF
1
R221
11016432j26
resistor 4.3K 1/6W,+/-5% CF
4
R201,202,217,218
11016472j26
resistor 4.7K 1/6W,+/-5% CF
1
R241
11016473j26
resistor 47K 1/6W,+/-5% CF
3
R231,232,233
11016512j26
resistor 5.1K 1/6W,+/-5% CF
1
R211
11016563j26
resistor 56K 1/6W,+/-5% CF
1
R207
11016912j26
resistor 9.1K 1/6W,+/-5% CF
1
R220
11010331j20
resistor 330 ohms 1W, +/-5% 20mm
1
R148
11350r10j20
ceramic resistor 0.1 ohms 5W,+/-5%
2
R130,131
11403302m0
trimer resistor 3K 0.3W +/-20%
1
VR102
115h104a1
variable resistor 100K
1
R214
Capacitors
129a184j633
plastic capacitor .18U 63V +/-5%
2
C213,214
129a394j633
plastic capacitor .39uF 63V +/-5%
2
C215,216
1302b101k503
disk capacitor 100P 50V +/-10%
2
C108,109
14
JBL S412P Amplifier PARTS LIST
