JBL STUDIO Series - Page 16

Part Number
Description
Q'ty
Designator
1302g472md00
disk capacitor 4700P 400V +/-20% UL
1
C001
1302b221k503
disk capacitor 220P 50V +/-10%
5
C131,201,202,211,221
1302f104m503
disk capacitor 0.1U 50V +/-20%
1
C107
1302f104z503
disk capacitor 0.1U 50V +80/-20%
10
C118,124,126,132,133,134,135,223,
227,228
1303f102k503
disk capacitor 0.001U 50V +/-10%
2
C137,207
1303f473m503
disk capacitor 0.047U 50V +/-20%
1
C212
130s1470k503
disk capacitor 47P 50V +/-10% @0.16
1
C222
132102j503
mylar capacitor 0.001U 50V +/-5%
1
C102
132104j503
mylar capacitor 0.1U 50V +/-5%
2
C112,136
132222j503
mylar capacitor 0.0022U 50V +/-5%
1
C101
132683j503
mylar capacitor 0.068U 50V +/-5%
2
C226,229
1353105m50
electrolytic capacitor 1U 50V+/-20%
2
C106,219
1353106m50
electrolytic capacitor 10U 50V+/-20%
5
C204,205,217,218,220
1353107m16
electrolytic capacitor 100uF 16V+/-20%
5
C115,117,127,128,225
1353107m50
electrolytic capacitor 100U 50V+/-20%
2
C110,111
1353227m16
electrolytic capacitor 220U 16V+/-20%
2
C116,224
1353476m25
electrolytic capacitor 47U 25 V+/-20%
5
C105,113,114,123,125
132223kb50
mylar capacitor 0.022uF 250V,+/-10% VDE
2
C129,130
1354478m50
electrolytic capacitor 4700uF 50V
2
C119,120
1354478m63
electrolytic capacitor 4700uF 63V
2
C121,122
Transistors
192027c1815gr
transistor 2sc1815gr @0.50
13
Q105,107,122,124,125,126,128,132,
133,201,203,205,206,207,
192027c2235y
transistor 2sc2235y
1
Q117
192028a1015gr
transistor 2sa1015gr @0.51
5
Q118,129,135,202,204
192028a965y
transistor 2sa965y
1
Q121
1921672n5551
transistor 2n5551
3
Q108,114,119
1921682n5401
transistor 2n5401 Ai-pnp 350V 500mA To-92
3
Q109,115,123
192021c1815gr
transistor 2sc1815gr
2
Q106,130
192021c5200o
transistor 2sc5200o
1
Q113
192021d669a
transistor 2sd669a
1
Q111
192022a1943o
transistor 2sa1943o
1
Q112
192022b649a
transistor 2sb649a
1
Q110
192161tip41c
transistor tip41c NPN SGS
1
Q120
192162tip42c
transistor tip42c PNP SGS
1
Q116
192201d882y
transistor ksd882y
1
Q131
192202b772y
transistor ksb772y
1
Q134
Integrated Circuits
19006m4558d
I.C. 4558D Dual Op-Amp
1
IC101
19016m311n
I.C. LM311 Comparator
1
IC102
19016t1074cn
I.C. TL074CN Quad Op-Amp
2
U201,202
Diodes
197131n4148
diode 1n4148
13
D103,106,107,109,111,201,202,203,
204,206,207,208,209
19915000333
zener diode 3.3V 1/2W
1
C205
19915000623
zener diode 6.2V 1/2W
1
D110
19915001503
zener diode 15V 1/2W
1
D114
19700kb1405
bridge diode 4A 500V KBL405
2
D112,113
197101n4002
diode 1N4002 @0.24
1
D108
197101n5402
diode 1N5402 @0.18
2
D104,105
Misc.
156b010010
isolating tube for light bulb
2
Q106,30
16250129001
cable assembly 120mm AWG28 white
1
171ugs2121
relay MI-SH-212L @22
1
RY101
06-m3085004
machine screw M3*8*P0.5
4
R/P to BRKT-4
06-m3125003
6
R/P to IC/H-6
06-m41013
machine screw M3*10
2
x'former-2
06-m4165009
machine screw M4*16
2
x'former-2
06-n4hw01
machine nut M4
2
x'former-2
