JBL STUDIO Series - Page 17

Part Number
Description
Q'ty
Designator
06-t3105007
screw M3*10
1
R/P to RCA jack-1
06-t4165016
screw 4*16
8
R/P to R/C-8
1010S412P
PCB ass'y
1
06-m30809
machine screw M3*8*P0.5
8
PCB to Brkt-8
06-t30804
screw 3*8
4
IC to H/S-2, PCB to H/S-2
101AS412P
AI Ass'y
1
1740rcb242v1
jack RCA RCB-242V-1
1
JK201
1751c02v01
connector 2pin 2.5mm pitch
2
P201,3
1751c07v01
connector 7pin 2.5mm pitch
1
P101
1751d02v01
connector 2pin 3.96mm pitch
1
P103
1751d05v01
connector 5pin 2.5mm pitch
1
P102
180tms7210v
switch slide 6pin MS7210V
2
SW202,3
650sub240
PCB holder L-type 1.6mm S.P.C.C.
4
653hs10
heat sink 23.5*16*25
2
Q110,1
150e0965502
transformer EI-96 TT096980307A
1
PT001
152ua22015
wire connector 12ft 2pin, blk, 40/6mm
1
154v40006t0
fuse TSD 4.0A,250V 20mm VDE
1
FS001
155520020
fuse holder R3-11
1
16210082007
wire red 18 AWG 80mm, #1015
1
16210605001
cable ass'y for speaker output
1
16210609002
cable ass'y for LED
1
16250602001
cable ass'y for HI-Level input
1
176wjce1
close end terminal CE-1
1
180pbr12c11s
power switch push BR12C11s
1
SW001
1932m1813
mica isolator To-220 18*13mm
2
Q116,20
1933m2520
mica isolator To-3P 25*22mm
2
Q112,3
640rp412
aluminum back panel 152.4*330.2*2.5
1
650ih125
IC holder
6
IC-6
700kb800
plastic knob 46077-W PVC
1
700rc10
housing 151.4*329.2*102 ABS90V-0
1
723a10
EVA gasket 300*14.2*1
4
723b10
EVA gasket 150.7*14.2*1
2
723c10
EVA gasket 150.7*14.2*1
2
725a125
rubber gasket 25*21*4
4
for XFORMER-4
1 set
156h020030
isolating tube 20mm*30mm
4
16210169001
cable ass'y 160mm awg26 wht/blk
2
19510336egw
Bipolar LED light 336EGW
2
700lt412
LED plate 140.8*24.7*2.6*17.6 silver/gray
1
713bp3000
LED holder, PP/blk
2
16
S412P LED Plate Ass'y
