116-161802F26-E resistor 18.0K 1/6W ±1% MF26mm TAP
(
RoHS
)
1 R21
130-2B102MJ03-E ca
p
acitor 1000
p
F 1000V Y5P20%TAP RoHS 1 C30
130-2B222MJ03-E ca
p
acitor 2200
p
F 1000V Y5P20%TAP RoHS 1 C2
135-3226M50-E ca
p
acitor 22U 50V ±20% TAP
(
RoHS
)
1 C8
135-B477M50A-E ca
p
acitor 105 470uF±20%50V LOWESR TAP 2 C21,C22
139-3227M16-E ca
p
acitor 220uF 16V±20% TAP
(
RoHS
)
2 C5,C26
139-B106M50-E LOWESR ca
p
acitor 10uF 50V 105 20% 1 C19
139-B107M16-E LOWESR ca
p
acitor 100uF 16V RoHS 2 C6,C27
139-B107M25-E LOWESR ca
p
acitor 100uF 25V RoHS 1 C31
154-V2500BT3-E slim fuse 2.5A 250V VDE TimeLa
g
1 F1
161-506520-E JUMPER WIRE 26mm TAP (RoHS) 9
J3,J4,J5,J6,J7,J8,J9,
J10,J1
190-16L431CLP1-E IC TL431CLP
(
RoHS
)
1 IC1
192-1672N3904-E transistor 2N3904 40V 200mA TO-92AI-NPN 1 Q4
192-1682N3906-E transistor 2N3906 40V 200mA TO-92AI-PNP 1 Q3
197-631N4148-E diobe 500mW 75V 1N4148 Pan
j
itTAP
(
RoHS
)
1 D5
118-08050000F-E SMD resistor 0 0805 1% RoHS 2 R12,R25
118-08051002F-E SMD resistor 10K 0805 1/10W ±1% LF
(
RoHS
)
3 R17,R26,R22
118-08052201F-E SMD resistor 2.2K 0805 1/10W 1%
(
RoHS
)
1 R16
118-08055101F-E SMD resistor 5.1K 0805 1/10W 1%
(
RoHS
)
2 R18,R13
118-08056801F-E SMD resistor 6.8K 0805 1/10W 1%
(
RoHS
)
1 R19
118-08058201F-E SMD resistor 0805 8.2K 1%
(
RoHS
)
1 R30
118-12061001F-E SMD resistor 1K 1206 1%
(
RoHS
)
1 R35
118-12061004F-E SMD resistor 1M 1206 1%
(
RoHS
)
2 R5,R8
118-120610R0J-E SMD resistor 10.0 1206 5%
(
RoHS
)
2 R2,R6
118-12061201F-E SMD resistor 1.2K 1206 1%
(
RoHS
)
1 R7
118-12062001J-E SMD resistor 2K 1206 5%
(
RoHS
)
1 R10
118-12062002F-E SMD resistor 20K 1206 1%
(
RoHS
)
1 R27
118-120622R0J-E SMD resistor 22 1206 5%
(
RoHS
)
2 R11,R39
118-12063002F-E SMD resistor 30K 1206 1%
(
RoHS
)
1 R41
118-12063002J-E SMD resistor 30K 1206 5%
(
RoHS
)
1 R24
118-120630R0J-E SMD resistor 1206 30 ±5%
(
RoHS
)
1 R28
118-12063902F-E SMD resistor 39.0K 1206 1%
(
RoHS
)
1 R36
118-12064700J-E SMD resistor 470 1206 5%
(
RoHS
)
1 R14
118-12065103J-E SMD resistor 510K 1206 5% RoHS 2 R1,R4
118-12065600J-E SMD resistor 560 1206 5%
(
RoHS
)
1 R15
118-120656R0J-E SMD resistor 1206 1/4W 56 ±5% LF 2 R32,R37
118-12066802J-E SMD resistor 68K 1206 5%
(
RoHS
)
2 R33,R34
141-B5105M50-E SMD ca
p
acitor 0805 Y5V 1uF 50V20%
(
RoHS
)
2 C13,C14
141-B7102J50-E SMD ca
p
acitor 0805 X7R 1nF 50V5%
(
RoHS
)
3 C11,C12,C15
141-B7103K50-E SMD ca
p
acitor 0.01U 50V X7R 0805
(
RoHS
)
1 C3
141-B7104K50-E
capacitor CAP SMD 0805 X7R0.1uF ±10% 50V
LF/RoHS
5 C7,C9,C16,C18,C29
141-C7104K50-E SMD ca
p
acitor 1206 X7R 0.1uF 50V10% RoHS 1 C17
141-C7104KA0-E SMD ca
p
acitor 1206 X7R 0.1uF100V ±10%
(
RoHS
)
1 C20
141-C7221KJ0-E SMD ca
p
acitor221P 1000V 10%1206 X7R
(
RoHS
)
2 C23,C24
141-C7474K50-E SMD ca
p
acitor 0.47uF 50V 1206X7R 10%
(
RoHS
)
1 C25
192-111BT3904S-E
SMD transistor MMBT3904 TRANSISTORSOT-23
NPN 40V 200MA
(
RoHS
)
1 Q5
192-991T4401S-E SMD transistor YG NPN MMBT4401 SOT-23 1 Q2
192-992T2907AS-E SMD transistor YG PNP MMBT2907A SOT-23 2 Q9,Q10
192-992T4403S-E SMD transistor YG PNP MMBT4403 SOT-23 2 Q1,Q8
197-03RLS4148S-E *SMD diobe RLS4148-TE11 ROHM
(
RoHS
)
2 D3,D7
197-0S4148WSP-E SMD diobe LL4148WSP 0805SHAWELL 4 D11,D12,D13,D14
199-6500075SJ-E
SMD diobe MINI-MELF 500mW5% 7.5V
ZMM5236B
(
RoHS
)
1 ZD3
199-6500150SJ-E
SMD diobe MINI-MELF 500mW5% 15V
ZMM5245B
(
RoHS
)
1 ZD2
199-6500240D-E diobe 24v 500mW SMT LL-34
(
RoHS
)
1 ZD1
104-A05317C00V-E PCB OF HKTS200 Control RoHS 0,125
PCB ASS'Y SUB140/230 POWER-SOURCE EUP RoHS
