141-A0101J50-E CAP SMD 0603 NPO100pF ±5% 50V LF/RoHS 6
C31,C32,C35,C36,C
79,C80
141-A0180J50-E CAP SMD 0603 NPO18
p
F ±5% 50V LF
(
RoHS
)
2 C67,C71
141-A0181J50-E SMD ca
p
acitor 0603 NPO 180PF 50V±5%
(
RoHS
)
2 C54,C55
141-A0221J50-E CAP SMD 0603 NPO220
p
F ±5% 50V LF 3 C37,C41,C44
141-A0470J50-E CAP SMD 0603 NPO47
p
F ±5% 50V LF 1 C22
141-A7104K50-E CAP SMD 0603 X7R0.1uF ±10% 50V LF 36
C1,C2,C3,C6,C11,C1
3,C15,C18,C19,C20,
C23,C24,C27,C29,C
33,C38,C43,C47,C50
,C51,C57,C58,C60,C
61,C62,C63,C65,C69
,C70,C72,C73,C74,C
81
,
C82
,
C84
,
C85
141-A7105K25-E SMD ca
p
acitor 1uF 0603 X7R 10%25V
(
RoHS
)
2 C56,C59
141-A7122K50-E SMD ca
p
acitor 1.2nF 0603 +/-10% 2 C4,C30
141-B0331JA0-E SMD ca
p
acitor 330
p
F 100V 5% 0805NPO RoHS 2 C7,C77
141-B5106Z16-E CAP SMD 0805 10uF+80/-20% 16V LF/RoHS 4 C10,C49,C52,C46
141-B7104KA0-E SMD ca
p
acitor 100nF 100V X7R 10%0805
(
RoHS
)
4 C5,C12,C14,C8
141-C7105K50-E SMD ca
p
acitor 1206 X7R 1uF 50V10% RoHS 4 C16,C21,C86,C87
142-SV226M16H-E SMD ca
p
acitor 22UF 16V 4.3*4.3mm
(
RoHS
)
4 C28,C45,C64,C75
190-998252ATS-E SMD IC MPC82x52AT TSSOP-20
(
RoHS
)
1 U3
190-154M5XNLS-E SMD IC NC7SZ04M5X
_
NL 1 U6
190-16CF4053S-E SMD IC HCF4053M013TRST SOIC16
(
RoHS
)
1 U8
190-16STA309S-E SMD ST IC STA309A13TR TQFP64
(
RoHS
)
1 IC2
190-16STA512BS-E SMD IC ST STA512B SO36 RoHS 1 IC1
190-16TL072DTS-E SMD I.C. TL072CDT SGS THOMSON
(
RoHS
)
2 U1,U9
190-99AP33GAS-E SMD IC AP6209-33GA 1 U7
190-99AP33GBS-E SMD IC AP6209-33GB 1 U5
190-99CS5343S-E SMD IC CS5343 CIRRUS LOGICTSSOP-10
(
RoHS
)
1 U2
190-99IMP809S-E SMD IC IMP809SEUR-T
(
IMP
)(
RoHS
)
1 U4
192-111BT3904S-E
SMD Transistor MMBT3904 TRANSISTORSOT-23
NPN 40V 200MA
(
RoHS
)
2 Q2,Q4
192-112BT3906S-E
SMD Transistor MMBT3906 TRANSISTORSOT-23
PNP 40V 200MA
(
RoHS
)
1 Q3
192-997C1815GRS-E SMT Transistor UTC MMBT1815 SOT-23RoHS 1 Q5
199-6500033SJ-E
SMD diode MINI-MELF 500mW5% 3.3V
ZMM5226B
(
RoHS
)
2 ZD1,ZD2
115-H102A101-E resistor 1KA 1 VR1
115-H104B107-E resistor 100KB 1 VR2
122-14220K06501-E
FERRITE CORE SD-500-311A CD21619P-
220KUS
(
RoHS
)
2 L1,L2
129-A684JA03-E ca
p
acitor 0.68U 63V ±5% MSCTAP
(
RoHS
)
1 C9
139-A108M63-E ca
p
acitor 1000uF 63V ±20%
(
16X31.5
)
(
RoHS
)
1 C17
145-11228800-E DIP Oscillator 12.288000MHz49S GB1220001 1 XL1
161-506520-E JUMPER WIRE 26mm TAP
(
RoHS
)
2 JP1,JP2
162-5010D020-E connector 100mm UL1007 24AWG 4PIN2.5Housin
g
1 CN6
162-5012D021-E connector 120mm UL1007 18AWG 1 CN1
174-0RCA313G-E RCA Jack RCA-313G
(
RoHS
)
1 JK1
175-1D02V01-E connector 2PIN PITCH=3.96mm
(
RoHS
)
1 CN2
175-9C04V03-E connector P=2.54mm 180
(
RoHS
)
1 CN4
180-TMS7210V-E SWITCH SLIDE 6PIN MS7210V
(
RoHS
)
2 SW1,SW2
195-401L0392-E diode R/G 3mm
(
RoHS
)
1 LD1
part no. description quantit
y
ref.
104-A05317B00V-E PCB OF HKTS200 PSU RoHS 0,5
110-122R2J52-E resistor 2.2 1/2W ±5% CF 52mmTAP
(
RoHS
)
1 R20
110-14220J52-E resistor 22 1/4W ±5% CF 52mmTAP
(
RoHS
)
1 R31
110-16103J52-E resistor 10K 1/6W ±5% CF 52mm TAPTAP
(
RoHS
)
2 R38,R40
PCB ASS'Y SUB140/230 POWER-SOURCE EUP RoHS
AMP JBL SUB140P/230 120W Eup (RoHS)
JBL
SUB
140P/230
Service
Manual
Page 9 of
28
