JBL Sub 6 - SUB6 PART LISTS (continued); Sub6 Electronic Components

Ref. No. Part No. Description Qty.
Resistors
R101, 107, QAF0650-332 RESISTOR 3.3K OHM 1/6W 5% CF 4
113, 119
R102, 111, QAF0650-103 10K OHM 1/6W 5% CF 10
132, 133,
140, 174,
178, 905,
906, 907
R103, QAF0650-473 RESISTOR 47K OHM 1/6W 5% CF 3
179, 180
R104, 136 QAF0650-683 RESISTOR 68K OHM 1/6W 5% CF 2
R105, 151 QHM2050-561 RESISTOR 560 OHM 2W 5% MF 2
P=20.0 mm
R106, 117, QAF0650-224 220K OHM 1/6W 5% CF 4
175, 176
R108 QAF0650-123 12K OHM 1/6W 5% CF 1
R109, 110, QAF0650-102 1K OHM 1/6W 5% CF 4
124, 130
R112 QAF0650-105 1.0M OHM 1/6W 5% CF 1
R114, 118, QAF0650-223 22K OHM 1/6W 5% CF 3
122
R115, 154, 172 QAF0650-104 100K OHM 1/6W 5% CF 3
R116 QAF0650-364 RESISTOR 360K OHM 1/6W 5% CF 1
R121 QAF0650-225 2.2M OHM 1/6W 5% CF 1
R125-128, QAF0650-153 15K OHM 1/6W 5% CF 6
144, 147
R131, 135 QAF0650-183 18K OHM 1/6W 5% CF 2
R134 QAF0650-203 20K OHM 1/6W 5% CF 1
R139, 170 QAF0650-222 2.2K OHM 1/6W 5% CF 2
R141 QAF0650-151 150 OHM 1/6W 5% CF 1
R142 QAF0650-122 1.2K OHM 1/6W 5% CF 1
R143 QAF0650-392 RESISTOR 3.9K OHM 1/6 5% CF 1
R145 QAF0650-391 RESISTOR 390 OHM 1/6W 5% CF 1
R148, 155 QHS0250-100 RESISTOR 10 OHM 1/2W 5% 2
R149, 150 QAF0250-100 10 OHM 1/2W 5% CF 2
R152-153 QHE5050-228 RESISTOR 0.22 OHM 5W 5% 2
CEMENT FIXED RES
Ref. No. Part No. Description Qty.
R156 QAF0650-563 RESISTOR 56K OHM 1/6W 5% CF 1
R169 QAF0650-333 RESISTOR 33K OHM 1/6W 5% CF 1
R171 QAF0450-222 2.2K OHM 1/4W 5% CF 1
340X2222934
R173 QAF0650-331 330 OHM 1/6W 5% CF 1
R177 QAF0650-474 RESISTOR 470K OHM 1/6W 5% CF 1
R181 QAF0650-274 270K OHM 1/6W 5% CF 1
R901-902 QHM1050-152 RESISTOR 1.5K OHM 1W 5% 2
METAL FILM
R903-904 QAF0650-154 RESISTOR 150K OHM 1/6W 5% CF 2
RD101 QAF0450-151 150 OHM 1/4W 5% CF 1
SVR101 QAF0650-202 2K OHM 1/6W 5% CF 1
ZD102 QAF0450-560 56 OHM 1/4W 5% CF 1
340X2560934
Diodes
BD101 RHD0402-001 RECTIFIER BRIDGE RS402L 4A 1
D101-105 RAD4001-001 RECTIFIER 1N4001 1A 35VRMS 5
D105-112 RAD4148-001 DIODE SW 1N4148 7
ZD101 RAZ0859-086 DIODE ZENR 17.5-18.3V .5W 1
HITACHI HZ18-2
ZD103 QAF0450-100 10 OHM 1/4W 5% CF 1
340X2100934
Transistors
Q101-105, RAN0945-001 XISTR NPN 2SC945P NEC 11
107, 109,
112, 114,
115, Q120
Q106, 108 RAP0733-001 PNP 2SA733Q,P NEC 2
Q121 RHP1264-001 XISTR PNP 2SA1264N-O TOSHIBA 1
Q122 RHN0882-001 XISTR NPN 2SD882P 1
Q123 RHN3181-001 XISTR NPN 2SC3181N-O TOSHIBA 1
Integrated Circuits
IC101 RHI0740-001 IC 14 PIN TL074CN 1
IC102 RHI4558-001 IC 8 PIN JRC4558D JRC OP AMP 1
SUB6 PART LISTS (continued)
Control Sub 6/10
10
