JBL Sub 6 - SUB6 PART LISTS (continued); Sub6 Miscellaneous Parts

Ref. No. Part No. Description Qty.
IC103 RHI1298-001 IC 14 PIN uPC1298V NEC 50-80W 1
POWER AMP DRV
IC104 RHI7815-001 IC 3 PIN 78L15 REGULATOR 1
POS. 15V 100mA
IC105 RHI7915-002 IC 3 PIN 79L15 REGULATOR 1
NEG. 15V 100mA
Miscellaneous
CN301 CCN1500-A18 CONNECTOR B2B-XH-A 2 PIN 1
GOLD OVER 50 uin
CN305A CCN1500-A42 CONNECTOR S2B-XH-A 2 PIN 1
GOLD OVER 50 uin
CN305A-305B 4999A-274 CON/WIRE 2 COND 200 mm 1
CON GOLD PLATING
CN305B CCN1500-A18 CONNECTOR B2B-XH-A 2 PIN 1
GOLD OVER 50 uin
CN306 CCN3951-002 CONNECTOR 2 PIN LEOCO 3951 1
P=3.96 POST BASE TOP
CN901 CCN3941-003 CONNECTOR 3 PIN PITCH=3.96mm 1
POST BASE TOP
CN902A CCN3951-003 CONNECTOR 3 PIN LEOCO 3951 1
P=3.96 POST BASE TOP
JK101 CJR6502-002 JACK RCA 1
2 TERM KUNMING
JK102 CTP0014-001 SPK JACK JYE TAI CJ-9011 1
8P JACK (R-B-B-R)
L101 SHR6619-001 RF COIL 1 uH 1
LD101 KEM0001-001 LED MULTI-COLOR LED TWO 1
COLORS RED/GRN CHANG
RB301 TO 5002ECE9BMM CON/WIRE 2 COND 350 mm 1
CON GOLD PLATING
RB302A-302B 2468824KCCK FLAT WIRE 8 1
240mm COLOR
RB303B TO 2468310KCCK FLAT WIRE 3 COND 100 mm 1
RB303A COLOR
RB304A-304B 2468724KCCK FLAT WIRE 7 1
240mm COLOR
RB306 TO 4999A-275 CON/WIRE 2 300 mm 1
CN306
RB307 TO 4999A-284 CON/WIRE 2 300 mm 1
SPEAKER
Ref. No. Part No. Description Qty.
RB902A TO 4999A-272 CON/WIRE 3 270 mm 1
CN902A
F101 KSD2315-001 3.15A GMC SLO-BLO, 1
5x20mm FUSE
RL101 MRL2212-002 RELAY MI-SH-212LM 12V DC 1
44 mA GOOD SKY
RL102 MRL2212-005 RELAY SHINMEI RPA-12V 1
DC 10A(AC)250V
SW101 MSR2612-001 SW ROTARY PHASE 1
SW102-103 MSS6542-002 SW SLIDE SS020-P022(2P2T) 2
VR101 MRR0503-011 50K x 2 DUAL GANG 1
FREQUENCY POT.
VR102 MRR0503-008 10K VOLUME POT. 1
w/ ON/OFF SWITCH
001X0776001 SIL PAD 3000+-500LBS BERQUIST 2
400 20x25mm
GAL0040-001 HEAT SINK JBL CM-6 60W BLACK 1
GSE0073-002 PCB BKT JBL CM-10/CM-6 2
GSI0001-001 SI RUBBER 13x18x0.3t mm 1
GSI0003-001 SI RUBBER 16x28x0.3t mm 1
SUB6 PART LISTS (continued)
Control Sub 6/10
11
