JBL Sub 6 - SUB10 PART LISTS (continued); Sub10 Electronic Components

Ref No. Part No. Description Qty.
C906-907 PRD3545-102 COND DISC 1000pF 50V 10% Y5P 2
Resistors
R101, 107, QAF0650-332 3.3K OHM 1/6W 5% CF 4
113, 119
R102, 111, 123, QAF0650-103 10K OHM 1/6W 5% CF 13
129, 132,
133, 140,
157, 174,
178, 905,
906, 907
R103, 179-180 QAF0650-473 47K OHM 1/6W 5% CF 3
R104 QAF0650-683 68K OHM 1/6W 5% CF 1
R105, 151 QHM2050-821 820 OHM 2W 5% 2
R106, 117, QAF0650-224 220K OHM 1/6W 5% CF 4
175-176
R108 QAF0650-123 12K OHM 1/6W 5% CF 1
R109, 110, QAF0650-102 1K OHM 1/6W 5% CF 4
124, 130
R112 QAF0650-105 1.0 OHM 1/6W 5% CF 1
R114, 118, 122 QAF0650-223 22K OHM 1/6W 5% CF 3
R115, 154, 172 QAF0650-104 100K OHM 1/6W 5% CF 3
R116 QAF0650-364 360K OHM 1/6W 5% CF 1
R141 QAF0650- 151 150 OHM 1/6W 5% CF 1
R142 QAF0650-122 1.2K OHM 1/6W 5% CF 1
R121 QAF0650-225 2.2M OHM 1/6W 5% CF 1
R125-128, QAF0650-153 15K OHM 1/6W 5% CF 6
144, 147
R131, 134-135 QAF0650-183 18K OHM 1/6W 5% CF 3
R136 QAF0650-164 160K OHM 1/6W 5% CF 1
R139, 170 QAF0650-222 2.2K OHM 1/6W 5% CF 2
R143 QAF0650-392 3.9K OHM 1/6W 5% CF 1
R145 QAF0650-391 390 OHM 1/6W 5% CF 1
R148, 155 QHS0250-100 10 OHM 1/2W 5% 2
FUSEABLE
R149-150 QAF0250-100 10 OHM 1/2W 5% CF 2
Ref No. Part No. Description Qty.
R152-153 QHE5050-228 0.22 OHM 5W 5% 2
CEMENT FIXED RES
R156 QAF0650-563 56K OHM 1/6W 5% CF 1
R169 QAF0650-333 33K OHM 1/6W 5% CF 1
R171 QAF0450-222 2.2K OHM 1/4W 5% CF 1
340X2222934
R173 QAF0650-331 330 OHM 1/6W 5% CF 1
R177 QAF0650-474 470K OHM 1/6W 5% CF 1
R181 QAF0650-274 270K OHM 1/6W 5% CF 1
R901-902 QHM1050-152 1.5K OHM 1W 5% 2
METAL FILM
R903-904 QAF0650-154 150K OHM 1/6W 5% CF 2
R905-907 QAF0650-103 10K OHM 1/6W 5% CF 3
RD101 QAF0450-151 150 OHM 1/4W 5% CF 1
SVR101 QAF0650-202 2K OHM 1/6W 5% CF 1
PVE3956-472 ELECT 4700 uF 63V 20% 2
DIA=25 PITCH=10 mm
ZD102 QHM1050-561 560 OHM 1W 5% 1
METAL FILM
Diodes
BD101 RHD0402-001 RECTIFIER BRIDGE RS402L 4A 1
D101-105 RAD4001-001 RECTIFIER 1N4001 1A 35VRMS 5
D106-112 RAD4148-001 DIODE SW 1N4148 7
ZD101 RAZ0859-089 DIODE 23.6-24.7V .5W 1
HITACHI HZ24-2
ZD103 RAZ0859-084 DIODE ZENR 14.5-15.1V .5W 1
HITACHI HZ15-2
Transistors
Q101-105, 109 RAN0945-001 XISTR NPN 2SC945P NEC 10
112, 114,
115, Q120
Q106, Q108 RAP0733-001 PNP 2SA733Q,P NEC 2
Q122 RHN0882-001 XISTR NPN 2SD882P 1
Q123 RHN3182-001 XISTR NPN 2SC3182N-O 1
Q121 RHP1265-001 PNP 2SA1265N-O 1
SUB10 PART LISTS (continued)
Control Sub 6/10
13
