JBL Sub 6 - SUB10 PART LISTS (continued); Sub10 ICs and Miscellaneous Parts

Ref No. Part No. Description Qty.
Integrated Circuits
IC101 RHI0740-001 IC 14 PIN TL074CN 1
IC102 RHI4558-001 IC 8 PIN JRC4558D JRC OP AMP 1
IC103 RHI1298-001 IC 14 PIN uPC1298V NEC 1
50-80W POWER AMP DRV
IC104 RHI7815-002 IC 3 PIN 78L15 REGULATOR 1
POS. 15V 100mA
IC105 RHI7915-002 IC 3 PIN 79L15 REGULATOR 1
NEG. 15V 100mA
Miscellaneous
4999A-275(x2), SLF0201-010 BEAD FERIT 3
CN301A CCN1500-A18 CONNECTOR B2B-XH-A 2 PIN 1
GOLD OVER 50 uin
CN305A CCN1500-A42 CONNECTOR S2B-XH-A 2 PIN 1
GOLD OVER 50 uin
CN305A TO 4999A-288 CON/WIRE 2 COND 280 mm 1
CON GOLD PLATING
CN305B CCN1500-A18 CONNECTOR B2B-XH-A 2 PIN 1
GOLD OVER 50 uin
CN306 CCN3951-002 CONNECTOR 2 PIN LEOCO 3951 1
P=3.96 POST BASE TOP
CN901 CCN3941-003 CONNECTOR 3 PIN PITCH= 1
3.96 mm POST BASE TOP
CN902A CCN3951-003 CONNECTOR 3 PIN LEOCO 3951 1
P=3.96 POST BASE TOP
F101 KSD2400-001 4A GMC SLO-BLO 1
5 x 20mm FUSE
JK101 CJR6502-002 JACK RCA HTJ032-24B-20 1
2 TERM KUNMING
JK102 CTP0014-001 SPK JACK JYE TAI CJ-9011 1
8P JACK (R-B-B-R)
L101 SHR6619-001 RF COIL 1 uH 1
LD101A KEM0001-001 LED MULTI-COLOR TWO COLORS 1
RED/GRN CHANG
RB301 TO 5002ECE9BMM CON/WIRE 2 COND 350 mm 1
CN301A CON GOLD PLATING
RB302A TO 2468824KCCK FLAT WIRE 8 COND 240 mm 1
RB302C COLOR
Ref No. Part No. Description Qty.
RB303C TO 2468310KCCK FLAT WIRE 3 COND 100 mm 1
RB303A COLOR
RB304A TO 2468724KCCK FLAT WIRE 7 COND 240 mm 1
RB304C COLOR
RB306 TO 4999A-275 CON/WIRE 2 COND 300 mm 1
CN306
RB307 TO 4999A-273 CON/WIRE 2 COND 340 mm 1
SPEAKER
RB902A TO 4999A-272 CON/WIRE 3 COND 270 mm 1
CN902A
RL101 MRL2212-002 RELAY 12V DC 1
44 mA GOOD SKY
RL102 MRL2212-005 RPA-12V DC 1
10A(AC)250V
SW101 MSR2612-001 SW ROTARY PHASE 1
SW102-103 MSS6542-002 SW SLIDE SS020-P022(2P2T) 2
T-MEC
VR101A MRR0503-011 50Kx2 DUAL GANG 1
FREQUENCY POT.
VR102A MRR0503-008 10K VOLUME POT. 1
w/ ON/OFF SWITCH
001X0776001 PAD 3000 +-500 LBS 2
BERQUIST 400 20x25mm
GAL0039-001 HEAT SINK JBL CM-10 100W BLK 1
GSE0073-002 PCB JBL CM-10/CM-6 2
GSI0001-001 SI RUBBER 13x18x0.3t mm 1
GSI0003-001 SI RUBBER 16x28x0.3t mm 1
