JBL SYNTHESIS SDP-25
TABLE OF CONTENTS
Introduction & Features ...................................................2
Installation & Setup ......................................................... 2
Front Panel Controls & Indicators ....................................3
Rear Panel Connections ................................................. 4
Remote Control .............................................................. 6
Input Connections .......................................................... 7
Output Connections ....................................................... 7
System Connections ....................................................... 8
Setup & Configuration ..................................................... 8
Operation ..................................................................... 12
Zone 2 Operation ......................................................... 13
Troubleshooting Guide .................................................. 14
Specifications ............................................................... 14
INTRODUCTION
Thank you for purchasing a JBL Synthesis SDP-25 Surround Sound Processor. You now have
at your command a unique product that has been designed to deliver the best possible sonic
performance regardless of the content being played, whether it is the latest blockbuster movie, a
major sporting event or your favorite music.
This Quick Start Guide is designed to give you the basic information needed to connect your
SDP-25 to the other components in your home theater system as well as to provide the basics
of setup and operation. For complete information on all that the SDP-25 has to offer please
download the full Owner’s Manual from the Support pages at www.jblsynthesis.com. Additional
support information may also be found in the Support Section of the JBL Synthesis web site.
Your dealer or installer is also a valuable resource and they may be able to assist you with
product questions. Of course, you may always contact JBL Synthesis Customer Service at
1-818-691-4171.
Welcome to the Synthesis family, we wish you many years of listening pleasure!
FEATURES
• Full suite of home theater audio formats
• Extensive connectivity options for up to twelve fully programmable audio/video sources
– Six HDMI inputs, including one on the front panel
– Two HDMI outputs, including one with ARC capability
– Composite and component video inputs for use with legacy video sources
– Five each optical and coaxial digital audio inputs and two each outputs
– 7.1 Direct audio inputs
– USB Audio input for connection to digital music servers
• Flexible control options including full-featured remote control, RS-232 and IR blaster
connections
• Software upgradeable via USB connection
• Rack ears included for custom mounting applications
INSTALLATION AND SETUP
INSTALLATION CONSIDERATIONS
To ensure optimal performance, please pay attention to the instructions in this Quick Start Guide.
• Install the SDP-25 on a solid, flat, level surface that is dry, well-ventilated and out of direct
sunlight.
• Do not place the SDP-25 directly on a carpeted surface or cover any of the ventilation holes.
• Do not install the SDP-25 on a surface that is unstable or unable to support all four feet.
• Do not install it directly above another product, and do not put another product directly on
top of the SDP-25.
• Do not expose the SDP-25 to high temperatures or humidity, steam, smoke or excessive
dampness or dust.
WHAT’S IN THE BOX
Your new SDP-25 should include the following items. If anything is missing please contact your
dealer or installer before contacting JBL Synthesis as they may have used it to install you new
product:
• AC Power Cord
• Remote Control
• Batteries for the Remote Control
• Right and Left “rack ears”
• Mounting screws for the rack ears and the cover screw for the remote are packing in a small
poly bag
• This Quick Start Guide
