Step 11: Assemble the front bracket interchangeable cover
Assemble T(front bracket interchangeable cover R), S (front bracket
interchangeable cover L), U(Rear bracket interchangeable cover L) and
V(Rear bracket interchangeable cover R) to car body, as shown in the
figure.
20
1. Assemble Z(Ceiling Rear Pillar) to X(ceiling rear pillar).
2. Fix it with 8 P(4*12 self-tapping screws) , tighten the screws, as shown in
the figure.
Step 11-2: Assemble the Ceiling
Z
P
1. Assemble Y(Ceiling) to car body.
2. Fix it with 4 P(4*12 self-tapping screws) , tighten the screws, as shown in
the figure.
Step 11-3: Assemble the Ceiling
P
