Maintenance
Electrical System
153 9821/6100-4 153
Figure 111.
A Primary fuse B Cover/Secondary fuses
Window Washer
Check (Level)
1. Make the machine safe.
Refer to: Maintenance Positions (Page 122).
2. Get access to the front window washer bottle.
Refer to: General (Page 123).
3. Remove the filler cap.
4. Fill the washer bottle with clean water. The liquid should contain a de-icing fluid to prevent it freezing.
Refer to: Fluids, Lubricants and Capacities (Page 173).
5. Replace the filler cap.
Do not use engine coolant antifreeze.
Do not use the window washer when there is no liquid in the washer bottle as it will cause damage to the motor.
