jcb 85Z-1 Quick Start Guide

65R-1, 67C-1, 85Z-1, 86C-1, 90Z-1, 100C-1 9
A Fuel gauge
B Engine speed
C Two speed status warning
D Lift overload status
E Seat belt status
F Service due warning
G Clock
H Hydraulic oil temperature
J Coolant temperature warning
K Dozer float status
L SAE / AUX status warning
M Auto idle status
N Engine power mode status
P Hydraulic active status
Fig 7
Normal Operating Screen
A High flow aux warning
B High flow aux warning – single acting
C Low flow aux mode warning
D High flow auxiliary max flow indicator
Fig 8
Auxiliary Screen
Power Modes
Icon Variants
Auxiliary Modes Hydraulics Active Mode
Heavy
mode
Eco
mode
AUX mode
(SAE)
Swing mode
(SAE)
Hydraulics
inactive mode
Hydraulics
active mode
AUX mode
(ISO)
Swing mode
(ISO)
