About the Product
Description
6
9831/0650-3
6
Description
Main Component Locations
Figure 2.
A
B
C
D
E
F
A
Access door for the control panel
B
Access door for engine and radiator
C
Access panel for exhaust muffler
D
Access door for alternator
E
Access door for battery
F
Forklift pockets
12
14
