Attachments
Working with Attachments
71 9831/0650-3 71
Figure 61. For G27QS Only
F
B
C
E
D
A
A Electrical installation B Generator installation
C Fuel system installation D G drive installation
E Battery installation F Base frame

Table of Contents

Question and Answer IconNeed help?

Do you have a question about the jcb G40QS and is the answer not in the manual?

jcb G40QS Specifications

General IconGeneral
ModelG40QS
Rated Power Output3.2kW
Voltage230V
Frequency50Hz
Fuel TypePetrol
Maximum Power Output3.5kW
Engine Type4-Stroke, OHV, Air Cooled
Starting SystemRecoil
