jcb JCB-E460P - Specification & Torque Settings and Tolerances

JCB-E460P
Instruction & User Manual
24
Mode
l
JCB
-E460P
Displacement
(cc)
457
Power
@3600rpm (hp)
17.4
Emission
Standard
eUV
-2
Bore x Stroke
92x69
Start
Method
Recoil
Fuel Tank Capacity (L)
6.5
Low Oil Sensor
Yes
Ignition System
CDI
Dimensions (mm)
LxWxH
480x420x460
Packaging Dimensions (mm)
LxWxH
550x450x490
Specifications
Inlet
Valve Clearance (mm)
0.08~0.12
Exhaust Valve Clearance (mm)
0.13~0.17
Big End Bolts(Nm)
19~21
Valve Rocker
Lock Nuts (Nm)
8~12
Rocker Cover Plate (Nm)
8~12
Crankcase Bolts (Nm)
26~30
Carburettor
Nuts (Nm)
9~11
Governor
arm Clamp bolt (Nm)
9~12
Exhaust Manifold
(Nm)
5~10
Head Bolts (Nm)
45~50
Flywheel Retention Nut (Nm)
100~120
Sump Plug (Nm)
30~40
Tightening Settings and Tolerances
