JCB-MS-254SB-L
Instruction & User Manual
COMPONENT LIST
18. Bevel scale
19. Bevel pointer
20. Locking screw for drag guide
21. Drag guide
22. Locking screw knob
23. Fastening bolt
24. Screw for cutting depth limiter
25. Stop for cutting depth limiter
26. Locking bolt
27. Support foot
28. Turn table release lever
29. Flange bolt
30. Outer flange
31. Spindle lock button
32. Inner flange
33. Laser
34. ON/OFF switch for laser
35. Laser compartment
36. Laser holder
37. Guide bar
34
23
26
22
18 19
20
21
6
31
24
25
28
