JCB-MS-254SB-L
Instruction & User Manual
COMPONENT LIST
1. Handle
2. ON/OFF switch
3. Lock-off lever
4. Machine head
5. Moving blade guard
6. Saw blade
7. Clamping device
8. Workpiece support
9. Locking screw for workpiece support
10. Table insert
11. Turn table locking handle
12. Pointer
13. Mitre scale
14. Turn table
15. Fixed saw table
16. Stop rail
16a Extension block
16b Set screw
17. Sawdust bag
33
36
9
8
11
10
1
4
5
7a
7
18
19
17
35
13 12 2714
16
15
37
16a/16b
2
3
behind the
Movable
blade guard
29
30
32
