Routine Maintenance
Fluids, Lubricants and Capacities
99 99
9811/5700-7
Fluids, Lubricants and Capacities
Table 1.
JCB recommend that you use the JCB lubricants shown as they have been verified by JCB for use on JCB machines.
However, you could use other lubricants that are equivalent to the JCB standards and quality or offer the same machine
component protection.
ITEM CAPACITY FLUID/LUBRICANT JCB PART
NO
Container
Size
(1)
(1) For information about the different container sizes that are available (and their part numbers), contact your JCB dealer
Litres UK Gallon
Fuel Tank 88 19.3 Diesel Oil K
Acceptable and Unacceptable Fuels ( T 101).
Engine (Oil)
(2)
(2) Caution - Do not use ordinary Engine Oil.
JCB Engine Oil EP 15W40 -10°C to
+50°C (14°F to 122°F)
4001/1805 20 Litres
MIN. 12 2.64
MAX. 15 3.3
JCB Engine Oil HP 10W30 -20°C to
40°C (-4°F to 104°F)
4001/1700 20 Litres
Engine (Coolant) 17 3.7 JCB Antifreeze HP Coolant/Water
K
Coolant Mixtures ( T 100)
4006/1120 20 Litres
Transmission
JCB Extreme Performance EP 10W
(3)
(3) Friction modified oils must not be used (e.g. Dexron ATF type).
4000/2505 20 Litres
2WD 17.3 3.8
4WD 18.3 4.0
Front Axle 29.5
(6.5)
29.5 (6.5) JCB Gear Oil HP Plus 4000/2205 20 Litres
Rear Axle (4WD) JCB Gear Oil HP90 4000/0305 20 Litres
Differential 15 3.3
Hubs (x2) 1.3 0.3
Brake System
JCB Hydraulic Fluid HP15
(4)
(4) Caution - Do not use ordinary brake fluid.
4002/0503 5 Litres
Hydraulic System 64
14
(5)
(5) This is nominal tank capacity. The total hydraulic system capacity depends on the equipment being used. Fill and check
with all rams closed. Watch level sight glass when filling.
JCB Hydraulic Fluid HP46 (Above 38
°C, 100 °F)
4002/0805 20 Litres
JCB Hydraulic Fluid HP32 (Below 38
°C, 100 °F)
4002/1025 20 Litres
Grease Points and Fork
Pivot pins
--- --- JCB Special HP Grease 4003/2017 400g
Mast Chains --- --- JCB Chain Lubricant 4004/
0237A
300ml
