06 - Access Cover
06 - Engine Compartment
06 - 13 9813/5250-1 06 - 13
Figure 14.
H
G
F
E
A
A Engine compartment cover
E Nuts 2
F Washers
G Bolts
H Hinges
4.5. Remove the engine compartment cover
from the machine.
Install
1. The installation procedure is the opposite of the
removal procedure.
