Technical Data
Parameter Value
Frequency 868,35 MHz
Codification High security rolling code
Memory
27 codes (expandable to 500 codes with memory
card)
Power supply 230Vac ±10%
Maximum motor power 750W / 1200W (intensive use / residential use)
Standby / operating consumption 23mA / 43mA
Motor fuses 6A
Optional cards RSEC3 + MEM 500 + V-XPAN + TL-CARD-V
Free voltage output 2 outputs
12Vdc output 1 fix (100mA) + 1 configurable (100mA)
Manoeuvre time 1 second – 6 minutes
Operating temperature -20ºCto +55ºC
Watertighness IP32
Size 180 x 152 x 88mm
jcmtechnologies
4
