Less pulse count (slow)
Less pulse count (slow)
Pulse count in 1 secound is within (+-)20% of reference value
More pulse count (fast)
More pulse count (fast)
LED1 LED2 LED3 LED4 LED5
Entrance Sensor
Centering Timing Sensor
Back Sensor
Head Exit Sensor
LED1:
LED2:
LED3:
LED4:
LED1:
LED2:
LED3:
LED4:
Detecting No Bill
Detecting Bill
CL3R Sensor
CL3I Sensor
AL2I Sensor
BL2G Sensor
LED1:
LED2:
LED3:
LED4:
LED1:
LED2:
LED3:
LED4:
Detecting No Bill
Detecting Bill
(VM-30 Mode Display LED)
5-3 Acceptor bill detection sensor ON/OFF test
The test result is shown on the acceptor's LEDs (red & green) and the VM-30 mode display LED1 to LED5.
(1) Test#1: The test of bill detection sensors
(2) Test#2: The test of bill detection by acceptor's validation sensors
