7 - 33
CHAPTER 7 Diagnostics
AL1R Sensor
BL1I Sensor
AR1R Sensor
BR1I Sensor
LED1:
LED2:
LED3:
LED4:
LED1:
LED2:
LED3:
LED4:
Detecting No Bill
Detecting Bill
AR2I Sensor
BR2G Sensor
BR3R Sensor
CR3R Sensor
LED1:
LED2:
LED3:
LED4:
LED1:
LED2:
LED3:
LED4:
Detecting No Bill
Detecting Bill
CC0I Sensor
DC0G Sensor
SSP Sensor
LED1:
LED2:
LED3:
LED1:
LED2:
LED3:
Detecting No Bill
Detecting Bill
(3) Test#3: The test of bill detection by acceptor's validation sensors
(4) Test#4: The test of bill detection by acceptor's validation sensors
(5) Test#5: The test of bill detection by Acceptor's validation sensors
