Section 7 iVIZION® Series Next-Generation Banknote Acceptor Unit Exploded Views & Parts Lists
iVIZION Transport Unit 1 Parts List
Table 7-5 iVIZION Transport Unit 1 Parts List
Ref No. EDP No. Description Qty Remark
401 147831 Transport Side Cover A 1
402 147832 Transport Side Cover B 1
403 147841 Transport Removal Arm A 1
404 147842 Transport Removal Arm B 1
405 147850 Side Sensor Cover 1
406 147851 Side Sensor Prism 1
407 147771 Connector Plate 1
408 147772 Transport GND Plate 1
409 147988 Spring Transport Latch 2
410 231080 Interface Connector Board Assy 1
411 148059 Home Position Sensor Board Assy 1
412 142636 USB FPC 1
413 146805 Interface FPC 1
414 146754 Power Supply FPC 1
415 146810 Home Position Sensor FFC 1
416 149788
2×5 Phillips, Self-Tapping, Binding Head Screw 3M (Black)
*
*. P-TITE is recommended.
2
417 148572
2×6 Phillips, Self-Tapping, Truss Head Screw 3M
*
2
418 082040
2.6×6 Phillips, Self-Tapping, Pan Head Screw 3M
*
1
419 104010
2.6×6 Phillips, Self-Tapping, Binding Head Screw 3M
*
3
420 023755 M2.6×4 Pan Head Screw with W Washer 3M (Small) 1
421 045969 M2.6×10 Pan Head Screw with W Washer 3M (Small) 2
422 137787 Φ1.6×10 Parallel Pin Sustainer (Hard) 2
423 104036 Φ4 E-Ring 2
