DC Pump
OWNER’S MANUAL
DCP-2500，DCP-3000，DCP-4000，DCP-5000，DCP-6500, DCP-8000,
DCP-10000， DCP-15000，DCP-18000，DCP-20000
Introduction
The DCP pumps are carefully inspected and tested to ensure both safety and operating
performance. However, failure to follow the instructions and warnings in this manual
may result in pump’s damage and/or serious injury. Be sure to read and save this
manual for future reference.
Pump Features
● High performance with innovative motor, and energy saving up to 65%, super
quiet operation.
● IC electronic detection, automatic power-off protection upon no water.
● No-copper element.
● Suitable for both marine and fresh water, Rust free.
● With anti-resistant ceramic shaft, Longer operation file.
Controller Features
● Adjustable the flow rate and head max.
● “Feed” Model, pause, timing, delay, restart function
● Memory function, ensure that the pump rework upon keeping the same parameter
Operating instructions
1. The pump must be connected with the controller and the 24V or 36V adaptor
correctly before work
2. Lock / unlock function:
press the "+" or "-" button for three seconds until the LED light flash for two times, the
controller locked; Similarly, press the "+" or "-" button for three seconds again, LED
indicator light flashes for two times, the controller unlocked
3. "FEED" function: when the pump is working, press "FEED" button, pump stops
working, the "10min" indicator lights up, the pump reworks automatically at previous
level after 10 minutes. Or you can press the “FEED” button to make the pump rework.
Control and Panel Function
First, LED display and controller key Instructions
As indicated in able diagram LED indicates power work/stop and fault code, the panel
are touched control
Seconds, operating instructions
After connected with pump, the control is set per last operation, panel is shown on LED,
touch work /stop button, the pump will stop working, and OFF indicate in LED. Touch
work/stop button again, the pump resume working, Led shows normal locking panel.
PXXX is shown in LED, P is short for power, there are 71 settings for working panel,
when touch slow/fast button, LED will show the instant working condition, you can set
different power per your need. When sets “watts “ button the Led display the “watts”
button were “FXX，button from 30 to 100”，SP is Speed shortening. More than 1 S no
setting “watts” button, the led auto change its display “watts” button.
Three, the key Lock Function
Turn on the power, press the "+" or "-" button for three seconds until the LED light
flash for two times, the controller locked; Similarly, press the "+" or "-" button for three
seconds again, LED indicator light flashes for two times, the controller unlocked
Four, The Led protected mode
