Jedia JMA-1410 - Front Panel Controls (Page 5); Input 4~10 Controls; Master 1, 2; EQ; Power Switch

4.󰼿INPUT󰼿4󰾝10󰼿CONTROLS4. INPUT 4~10 CONTROLS
3
These make adjustment of MIC/LINE for input 4~10.
Adjust output level so as not to tune "on" clip LED under two 0'clock.
This is master volume for all input levels you and better use toward
two 0'clock adjust level before clipping for proper operation.
5. MAST 1, 2 /EQ
This is power switch.
6. POWER SWITCH
OUTPUT SWITCH
This is selector that send signal of input 4~10 to the master-output.
When input 1~3 signal and chime signal are supplied, priority
will be activated and close output of input 4~10.
This is selector that send signal of input 2, 3 to the master output
when input 2~3 are activated, signal of input 4~10 will be close.
입력󰼿4󰾝10의󰼿마이크/라인󰼿신호레벨을󰼿조정할󰼿수󰼿있으며󰼿통상󰼿조정위
치는󰼿마스터󰼿볼륨이󰼿2󰾝3시󰼿방향으로󰼿조정된󰼿상태에서󰼿출력󰼿레벨󰼿메터
의󰼿+3󰼿LED가󰼿켜지지󰼿않도록󰼿레벨󰼿볼륨을󰼿조정하십시오.󰼿
그리고󰼿신호󰼿입력이󰼿되면󰼿시그널󰼿LED가󰼿켜집니다.
5.󰼿MASTER󰼿1,2󰼿/󰼿EQ
모든󰼿입력󰼿신호󰼿레벨을󰼿최종으로󰼿조정하며󰼿통상󰼿운용위치는󰼿2󰾝3시󰼿
방향이󰼿적당합니다.
운용시󰼿가능하면󰼿출력󰼿메터의󰼿+3󰼿LED가󰼿켜지지󰼿않는󰼿상태로󰼿레벨을󰼿
조정하십시오.
6.󰼿POWER󰼿SWITCH
누르면󰼿전원이󰼿공급되고󰼿전원󰼿LED가󰼿켜집니다.
EQUALIZER
Adjust low, high if EQ volume according to condition.
OUTPUT󰼿SWITCH
입력󰼿4󰾝10의󰼿신호를󰼿마스터󰼿출력으로󰼿보내기󰼿위한󰼿신호󰼿선택󰼿스위
치󰼿입니다.
챠임󰼿및󰼿입력󰼿1󰾝3의󰼿신호가󰼿출력되면󰼿우선권이󰼿동작하여󰼿4󰾝10번󰼿
출력이󰼿차단됩니다.
음량󰼿조절기
설치󰼿장소의󰼿특성에󰼿맞도록󰼿LOW󰼿및󰼿HIGH󰼿EQ󰼿볼륨으로󰼿조절하십
시오.
MODE󰼿SWITCH
신호󰼿입력을󰼿선택하는󰼿스위치󰼿입니다.
MIC󰼿󰼿󰼿󰼿󰼿󰼿󰼿󰼿:󰼿300Hz󰼿H.P.F󰼿마이크󰼿입력󰼿선택󰼿위치이며󰼿실내공명󰼿주
파수,󰼿교통소음,󰼿바람소리,󰼿파열음등의󰼿소리를󰼿제거하여󰼿명료도를󰼿
향상시킵니다.
MIC󰼿󰼿󰼿󰼿󰼿󰼿󰼿󰼿:󰼿필터󰼿기능이󰼿없는󰼿마이크󰼿입력󰼿선택󰼿위치입니다.
LINE󰼿:󰼿라인󰼿입력󰼿선택󰼿위치이며󰼿CD,󰼿카세트,󰼿튜너󰼿등의󰼿라인레벨󰼿
출력󰼿제품으로부터󰼿신호공급이󰼿가능합니다.
IMPORTANT NOTICE : Selecting mode switch " "(HPF)," "
(flat) power will be supplied to input XLR connector for condensor
mic only. If you connect unbalanced dynamic microphone with them,
it may be defaulted and should be minimized level volume before
moving to mode switch for noise down.
MODE SWITCH
MIC : It is input mic switch of 300Hz H.P.F that makes sound
clearance. When you select switch, windy sound.
Resonance frequency, plosive sound will be removed.
MIC : This is MIC input switch without filter line.
LINE : Line input for CD CASSETTE, TUNER.
중요사항󰼿:󰼿모든󰼿스위치를󰼿󰼿󰼿󰼿󰼿󰼿,󰼿󰼿󰼿󰼿󰼿위치에󰼿선택시는󰼿컨덴사󰼿
마이크󰼿공급용󰼿전원이󰼿입력󰼿XLR잭에󰼿공급되도록󰼿설계되어󰼿
있습니다.󰼿언바란스󰼿다이나믹󰼿마이크를󰼿연결하면󰼿마이크󰼿유
니트가󰼿고장납니다.󰼿그리고󰼿레벨󰼿볼륨을󰼿최소로󰼿돌린󰼿상태에
서󰼿모드스위치를󰼿전환해야󰼿스위치󰼿이송시󰼿잡음󰼿출력이󰼿차단
됩니다.
F
RONT PANEL CONTROLS (전면기능)
