Jedia MOBILE 35 - Front Panel Controls; Power Switch; Tone Filter; Volume Controls

2
1.󰼿전원󰼿스위치
이󰼿스위치를󰼿누르면󰼿파워󰼿표시기󰼿LED에󰼿불이󰼿들어오고,󰼿기기에󰼿전원이󰼿
공급된다.
저역과󰼿고역󰼿필터를󰼿사용하여󰼿음질의󰼿명료도를󰼿높일󰼿수󰼿있다.
2.󰼿톤󰼿필터
JTP-10A,󰼿JCP-10,󰼿JCR-10,󰼿JDM-10A등을󰼿장착하여󰼿사용할󰼿수󰼿있다.󰼿
5.󰼿모듈󰼿삽입구
MIC,󰼿AUX󰼿그리고󰼿테이프󰼿입력󰼿잭으로부터󰼿입력신호의󰼿조절이󰼿이루어짐.󰼿
레벨󰼿미터는󰼿항상󰼿0dB󰼿지점으로󰼿조정󰼿되어야만󰼿함.
3.󰼿볼륨󰼿조절기
출력󰼿신호의󰼿크기를󰼿보여준다.󰼿
4.󰼿출력󰼿레벨󰼿표시기
1. POWER SWITCH
2. TONE FILTER
5. BLANK PANEL
3. VOLUME CONTROLS
4. OUTPUT LEVEL DISPLAY
In order to increase a clearance of tone quality and reduce inside
resonance sound according to frequency quality for speaker play
-back or operating place, user should adjust high, Low filter.
Then, it provides clear sound to user.
Pressing this switch to ON will light the power indicator LED and
supply the power to the unit.
Out signal of amplifier can be adjusted by control of input signal
from MIC, AUX and tape input jack.
Besides level meter always should be adjusted to point at 0dB.
These displays indicate the output level.
FM/AM TUNER(JTP-10A) or CASSETTE DECK(JCP-10) or
CASSETTE RECEIVER(JCR-10) or DIGITAL MESSAGE(JDM-10A)
as module type(+10V only).
F
RONT PANEL CONTROLS (전면기능)
MIC-1
MIC-2
MIC-3 / AUX-1
AUX-2 / TAPE
POWER
3
13
MIXING POWER AMPLIFIER
8
3
0
LOW
HIGH
TONE
ON
LEVEL METER
MOBILE 60
40
400
350
130
240
2.5
20
KHz
4
15
10
Hz
MIN MAXMIN MAXMIN MAX MIN MAX
5
3
2
1
4
