Jeep Compass 2013 - Page 475

Cavity Car-
tridge
Fuse
Mini-
Fuse
Description
1 Empty Empty
2 15 Amp
Lt Blue
AWD/4WD Control
Module – If Equipped
3 10 Amp
Red
Rear Center Brake
Light Switch
4 10 Amp
Red
Ignition Switch/
Occupant Classifica-
tion Module
5 20 Amp
Yellow
Trailer Tow –
If Equipped
Cavity Car-
tridge
Fuse
Mini-
Fuse
Description
6 10 Amp
Red
Power Mirror/
Steering Control
Satellite Radio/
Hands-Free Phone
7 30 Amp
Green
Ignition Off Draw
8 30 Amp
Green
Ignition Off Draw
9 40 Amp
Green
Power Seats
10 20 Amp
Yellow
Power Locks/Interior
Lighting
7
MAINTAINING YOUR VEHICLE 473
