Cavity Car-
tridge
Fuse
Mini-
Fuse
Description
11 15 Amp
Lt Blue
Power Outlet
12 20 Amp
Yellow
115V AC Inverter –
If Equipped
13 20 Amp
Yellow
Cigar Lighter
14 10 Amp
Red
Instrument Cluster
15 40 Amp
Green
Radiator Fan
16 15 Amp
Lt Blue
Dome Lamp/
Sunroof/Rear
Wiper Motor
Cavity Car-
tridge
Fuse
Mini-
Fuse
Description
17 10 Amp
Red
Wireless Control
Module
18 40 Amp
Green
Auto Shutdown Relay
19 20 Amp
Yellow
Radio Amplifiers
20 15 Amp
Lt Blue
Radio
21 10 Amp
Red
Intrusion Module/
Siren – If Equipped
22 10 Amp
Red
Heating, AC/Compass
474 MAINTAINING YOUR VEHICLE
