Cavity Car-
tridge
Fuse
Mini-
Fuse
Description
23 15 Amp
Lt Blue
Auto Shutdown Relay
24 15 Amp
Lt Blue
Power Sunroof –
If Equipped
25 10 Amp
Red
Heated Mirror –
If Equipped
26 15 Amp
Lt Blue
Auto Shutdown Relay
27 10 Amp
Red
Airbag Control
Module
28 10 Amp
Red
Airbag Control
Module/Occupant
Classification Module
Cavity Car-
tridge
Fuse
Mini-
Fuse
Description
29 Hot Car (No Fuse
Required)
30 20 Amp
Yellow
Heated Seat –
If Equipped
31 10 Amp
Red
Headlamp Washer –
If Equipped
32 30 Amp
Pink
Auto Shutdown Relay
33 10 Amp
Red
J1962 Conn/
Powertrain Control
Module
34 30 Amp
Pink
Antilock BrakeValve
7
MAINTAINING YOUR VEHICLE 475
