74 GETTING TO KNOW YOUR VEHICLE
NOTE:
All lowering and raising the soft top instruc-
tions are applicable to both two and four door
model vehicles.
Images shown are of four door models, and
appearance of two door model components
may differ.
The following options are available to you when
lowering your vehicle’s soft top:
Sunrider® position with rear and quarter
windows installed
Sunrider® position with rear and quarter
panels removed
Sunrider® position with rear window
installed and quarter panels removed
Fully lowered position with rear and quarter
windows removed
Both quarter windows should be removed and
installed together.
Lowering The Soft Top Into Sunrider® Position
1. Fold both sun visors forward against the
windshield.
2. Release the header latches from the
crossbar by pulling the handle downward.
Make sure the hook is disengaged from its
receiver.
Step Two
3. From both the left and right sides, lift up on
the #1 Bow of the soft top to start the
operation.
Step Three
4. Move to the side of the vehicle and use the
side link to fold the soft top rearward into
the Sunrider® position.
Step Four
NOTE:
If leaving the soft top in the Sunrider® position,
secure the top by using the two hook-and-loop
fasteners provided in the center console.
Step Four
