GETTING TO KNOW YOUR VEHICLE 75
NOTE:
The vehicle can be driven in the Sunrider®
position with the rear window and quarter
panel assemblies fully installed or completely
removed.
The rear window and rear quarter windows
must be removed before fully lowering the
soft top to prevent damage to the top. Clean
the side and rear windows before removal to
assist in preventing scratching during
removal of the soft top. If the plastic retainers
are difficult to operate due to road dust, etc.,
clean them with a mild soap solution and a
small brush. Cleaning products are available
through an authorized dealer.
Removing The Soft Top Windows
NOTE:
Before fully lowering the soft top, the rear
window and rear quarter windows must be
removed.
Remove The Rear Window:
1. With the swing gate open, remove the rear
window’s plastic retainers from the lower
right and left corners.
Step One
2. Grab the swing gate bar, rotate it outward
and upward releasing it from both the right
and left retainers.
Step Two (Left Side Shown)
3. While holding the window in place, slide the
swing gate bar to the left separating it from
the rear window. Store in soft window bag (if
equipped), or a safe location.
Step Three
4. Remove the plastic retainers from both
quarter window pillars.
Step Four
2
