JENCO VisionPlus pH6175 - Installing the Batteries; Display & Keys Functions; Display

3
adaptor supplied with the instrument to make sure that the AC line
voltage is correct. If the wrong AC adaptor is supplied, notify your
Jenco representative immediately.
INSTALLING THE BATTERIES
To insert the batteries into the meter, follow the procedure outlined
below.
1. Use two hands to flip the two buckles and battery cover to
expose the battery compartment. (Figure 1.)
2. Note the polarity and insert the six AAA batteries into the
battery compartment correctly.
3. Replace the battery cover.
4.
Figure 1: Battery compartment
DISPLAY & KEYS FUNCTIONS
A. Display
1
2
3
4
5
6
7
9
10
12
11
8
Figure2: Active LCD screen
