Jensen JCD3006 User Manual

JCD3006
5
WIRING
Power Antenna
Connect to power antenna or amplifier,
If not used, tape bare end of wire.
Ground
Connect to ground terminal or clean
unpainted metal part of chassis.
Memory / Battery
Connect to battery or 12 volt power source
that is always live. The radio will not work if
this wire is not connected.
Accessory / Ignition
Connect to existing radio wire or radio fuse.
12
3
4
5
6
7
8
9
10
11 12
13
14
15
16
17
18
19
20
Figure 1: 20 PIN HARNESS PIN CHART
PIN WIRE COLOR FUNCTION / LABEL
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
GREY / BLACK
GREY
VIOLET
VIOLET/BLACK
GREEN
GREEN / BLACK
RED
BLACK
RED
WHITE
WHITE / BLACK
BLUE
YELLOW
BLACK
WHITE
RIGHT FRONT SPEAKER ( )
LEFT REAR SPEAKER (+)
N/A
LEFT FRONT SPEAKER (+)
CHASSIS GROUND
LEFT REAR PRE-AMPLIFIER LINE OUT
LEFT FRONT SPEAKER ( )
POWER ANTENNA
BATTERY (+)
RIGHT FRONT SPEAKER (+)
RIGHT REAR SPEAKER (+)
RIGHT REAR SPEAKER ( )
LEFT REAR SPEAKER ( )
IGNITION (ACC)
REAR PRE-AMPLIFIER LINE OUT COMMON
RIGHT REAR PRE-AMPLIFIER LINE OUT
EMPTY
GREY-BLACK RF-
VIOLET-BLACK RR-
RED
YELLOW
BLACK
BLUE
VIOLET RR+
GREY RF+
GREEN-BLACK LR-
WHITE-BLACK LF-
GREEN LR+
WHITE LF+
RIGHT REAR
RIGHT FRONT
LEFT REAR
LEFT FRONT
GREY
688A
FUSE
REAR LINE OUT
RED
R-CH
WHITE
L-CH
AMP
HARNESS
AUDIO/POWER
20-PIN
(See Figure 1)
ANTENNA
JACK
RCA-TO-RCA CABLE
(not supplied)
ANTENNA SOCKET
N/A
EMPTY
N/A
EMPTY
N/A
EMPTY
N/A
EMPTY

Jensen JCD3006 Specifications

General

Brand	Jensen
Model	JCD3006
Category	Car Stereo System
Language	English
