4
CONTROL to select from the following Beep
Tone options:
• BEEP ALL: Beep is heard any time a
button is pressed (function activated).
• BEEP 2ND: Beep is heard only when a
secondary function is activated (press and
hold).
• BEEP OFF: Beep is not heard.
Liquid Crystal Display (LCD)
The liquid crystal display (LCD) panel (8)
displays the frequency, time and activated
functions of the unit.
NOTE: After being subjected to cold
temperatures, LCD panels may take longer
to respond and visibility of the numbers on
the LCD may decrease slightly. The LCD
display will return to normal when the
temperature increases to a normal range.
Display (DISP)
When the unit is on, the LCD automatically
shows the display for the current source of
operation.
When the unit is on, press the DISP button (9)
to display the time of day. After five seconds,
the display reverts to the current source.
Setting the Clock
1. Turn the unit on.
2. Press the DISP button to display the clock.
3. When the clock is displayed, press and
hold the DISP button until the time begins
to flash.
4. Use the >> button to set the hour.
5. Use the << button to set the minutes.
6. After 5 seconds, the clock will time out and
return to the previous display. The time is
now set.
Auxiliary Input
Lift the cover on the right side of the radio to
reveal the AUX IN connector (16).
Front Panel Release
The front panel REL (release) button (10)
releases the mechanism that holds the front
panel to the chassis.
Detaching the Front Panel
To detach the front panel, first press the REL
button (10) to release the left side of the panel.
Next, grasp the released side and pull the panel
off the chassis. After removing the front panel,
store it in the supplied carrying case to protect it
from dirt and damage.
Re-attaching the Front Panel
To re-attach the front panel, make sure the
electrical terminals on the back of the panel are
free of dust and dirt, as debris could cause
intermittent operation or other malfunctions.
Position the right side of the panel in place so
that it is correctly engaged, and then lightly
press the left side of the panel until the panel
locks into place.
