operation instructions page 21
Spare parts ICEB 4-roll wire feed 42V, 130/140/150W
Spare parts ICEB 4-roll wire feed 42V, 130/140/150W
Item
Designation
Stock number
1
Carbon brush 130W complete
457.130.061
Carbon brush 140W
457.140.001
Carbon brush 150W
457.150.057
2
Brushing cover 140/150W
457.140.002
3
Stator 140W
457.140.046
Stator 150W
457.150.051
4
Eyelet bolt M8
457.140.004
5
Feather D10 x 0,5 x 70 mm
457.140.005
6
Feather holder
457.140.006
7
Feather for gripping screw 13 x 2,5 x 43
457.140.007
8
Gripping screw D30 mm, M8
457.140.008
9
Cap screw M6 x 12
D912 M6x8
10
Motor armature 140W complete
457.140.010
Motor armature 150W complete
457.150.052
11
Ball bearing 12x32x10 mm, 6201 2RS
285.201.001
12
Hexagon head cap screw M4 x 110 for 140W
457.140.012
Stud bolt M4 for 150W
457.150.054
13
Gearbox case
457.140.013
