Jet Inc. 750 Alpha Drive Cleveland, OH 44143 www.jetincorp.com 800.321.6960
QA-SAL-132 REV 7/31/2013
SAMPLE HUB AND CONNECTOR INSTALLTION
INSTRUCTIONS
Carflex Fittings Installation Instructions
LT43C-CAR, LT43F thru J, LT20C-CAR, LT20F thru J.
1. Cut the end of the Carflex conduit or Carflex® X-Flex™ tubing square.
2. Install compression nut and sealing gland ring over the end of the conduit or tubing.
3. Insert the ferrule end of the fitting into the conduit using a clockwise twisting action.
4. Screw fitting body into compression nut.
5. When installation is completed, use a wrench, tighten compression nut one-quarter
(1/4) turn past hand-tight. Do not over tighten fitting.
*To prevent damage to conductors, conduit and fittings, do not twist Carflex during
installation.
LT43D-New, LT43E-New, LT20D-New, LT20E-New.
1. Cut the end of the Carflex conduit or Carflex® X-Flex™ tubing square.
2. Install compression nut over the end of the conduit or tubing.
3. Insert the ferrule end of the fitting into the conduit using a clockwise twisting action.
(Be sure conduit is fully inserted to the bottom of the fitting shoulder).
4. Screw compression nut onto fitting body.
5. Use a wrench, and tighten compression nut one (1) full turn past hand-tight. Do not
over tighten fitting.
*To prevent damage to conductors, conduit and
fittings, do not twist Carflex during installation.
