Troubleshooting Guide
Problem
Probable Cause
Solution
No Power to Panel
• No power from main
breaker panel
• Internal panel power
switch in off position
• Check wiring and
main breaker panel
• Check on/off
switch
Aerator Alarm After Start
Up
• Aerators not connected
and running
• DIP aerator selection
incorrect
• Aerator/Compressor
DIP setting incorrect
• Check aerator(s)
and connections
• Confirm DIP
settings are correct
for system design
Auxiliary Alarm After Start
Up
• Alarm settings incorrect
(NO/NC)
• Alarm or float condition
is active
• Check alarm
setting jumpers for
proper NO/NC
• Check external
devices and floats
No Power to Aerators
• Inbound power inactive
• Timer setting in “Off”
cycle
• Check connections
and main breaker
panel
• Reset panel to
override “Off” cycle
No Power to Pump
• Inbound power inactive
• Alarm condition active
• Check connections
and main breaker
panel
• Resolve alarm
conditions
Auxiliary Outputs Inactive
• DIP settings incorrect
• Excessive load on
external device
• Check DIP settings
• Confirm power
requirements for
external device
Aerator Timer Not
Functioning
• Incorrect DIP settings • Check DIP settings
Aerator Reset Not
Functioning
• External reset locked
out
• External toggle not
contacting button
• Reset panel with
Master Reset
button
• Adjust depth of
external toggle
Aerator Alarm with
Compressor
• DIP not set to
compressor function
• Check DIP setting
Alarms not Functioning
• Automated reset
program active
(Normal Function)
• Toggle test mode
“ON” if instant
alarms desired
