12
4. Remove the fence, and clean the guide tube
surface with alcohol. Peel off some of the
scale backing, and align the zero point of
the scale with your mark on the guide tube.
See Figure 17. Position the scale far
enough from the edge so that it can be read
easily through the cursor lens. Continue to
peel the backing and apply the scale, while
keeping the scale as straight as possible
along the guide tube.
5. Connect the saw to power and make a test
cut. Carefully measure the width of the cut
board and adjust the fence cursor to match
this measurement.
NOTE: Cursor position should be inspected
after each blade change. Always make test cuts
to verify settings.
Figure 16
Figure 17
