Jet IBG-8VS User Manual

6
4.0 Specifications
Model number
IBG-8VS
Stock number
578208-RU
Motor and Electricals
Motor type
Totally enclosed fan-cooled induction with inverter
Horsepower (true output)
0.75 kW
Motor phase
3
Voltage
230
Input power
single phase
Cycle
50 Hz
Listed FLA (full load amps)
3.5 A
On/off switch
TACT switch
Motor speed
Variable, 900-3600 /min
Power cable size
H05VV-F 1.0mm² x 3G, 182 cm
Power plug installed
VDE, 250V/16A
Recommended circuit size
1
15A
Sound emission without load
2
75 dB at 1 M
Arbor and grinding wheels
Arbor diameter
15.875 mm
Wheel size (dia. x width)
200 x 25 mm
Wheel bore
15.875 mm
Wheel material
aluminum oxide
Wheel grits
36 and 60
Wheel flange diameter
85 mm
Wheel speed
Variable, 900-3600 RPM
Arbor nut maximum tightening torque
270 kgf•cm
Tool rest distance to wheel
adjustable
Main materials
Arbor
Steel
Base
Cast iron
Motor housing
Sheet metal
Inner wheel guard
Cast iron
Outer wheel guard
Aluminum
Flange washers
Cast iron
Tool rests
Cast iron
Eye shields
Clear polycarbonate
Spark guards
Steel
Knobs
Polymide
Connector sleeve
ABS
T-fitting
ABS
Dimensions
Mounting hole centers
215 mm
Mounting hole diameters
11 mm
Footprint (width x depth)
241.6 x 205 mm
Assembled dimensions (LxWxH)
572 x 340 x 354 mm
Shipping dimensions (LxWxH)
580 x 342 x 356 mm
Dust/swarf collection
Dust port outside diameter
63.5 mm
Required min. extraction volume
350 CFM
Weights
Net weight
30.14 kg
Shipping weight
32.55 kg
