Check Box When This Step is Complete
SECTION # 3 WEIGHS APPROX. 150 POUNDS. THE
TWO PEOPLE WHO WILL INSTALL THIS SHOULD BE
ABLE TO LIFT THAT AMOUNT OF WEIGHT ABOVE
THEIR HEADS FOR AN EXTENDED PERIOD OF TIME. IF
TWO PEOPLE CANNOT SAFELY LIFT THE SECTION -
SEEK ADDITIONAL ADULT HELP BEFORE INSTALLING
ONTO THE GAME!
Each person should take a side and lift initially as shown in the
picture to the right. Be careful not to put too much pressure onto the
acrylic which extends out below the bottom of the metal cabinet.
Test the weight of the unit before proceeding.
SECTION # 3 WEIGHS APPROX. 150 POUNDS. THE
TWO PEOPLE WHO WILL INSTALL THIS SHOULD BE
ABLE TO LIFT THAT AMOUNT OF WEIGHT ABOVE
THEIR HEADS FOR AN EXTENDED PERIOD OF TIME.
The safest place to lift section # 3 onto the main cabinet (Section # 2)
- is from the rear of the game. This will prevent any resting of the
section on the large piece of glass on the front of the main cabinet.
You will need either two step stools or two ladders. This will help in
getting the unit high enough to guide it into the mounting holes.
Take note not to exceed the weight capacity of the ladder or stool.
SECTION # 3 WEIGHS APPROX. 150 POUNDS. THE
TWO PEOPLE WHO WILL INSTALL THIS SHOULD BE
ABLE TO LIFT THAT AMOUNT OF WEIGHT ABOVE
THEIR HEADS FOR AN EXTENDED PERIOD OF TIME.
Safely walk the piece around the back of the game. Make sure that
there are no customers around this area.
Check Box When This Step is Complete
Preparing the proper placement of section # 3 - Cont.
Testing the weight of section # 3
INSTALLATION INSTRUCTIONS
Check Box When This Step is Complete
Preparing the proper placement of section # 3
Jennison Entertainment Technologies Space Ballz Service Manual Page 16
