Jet SPACE BALLZ - Main Board Outputs

MAIN BOARD OUTPUTS - (THROUGH VERSION 20110413.A)
SPACE BALLZ - MAIN BOARD OUTPUT CHART
OUTPUT #
CONTENT
OUTPUT #
CONTENT
1
SIDE LIGHT # 1
2
SIDE LIGHT # 2
8
SIDE LIGHT # 8
9
SIDE LIGHT # 9
10
BONUS LIGHT # 1
11
BONUS LIGHT # 2
12
BONUS LIGHT # 3
3
SIDE LIGHT # 3
4
SIDE LIGHT # 4
5
SIDE LIGHT # 5
6
SIDE LIGHT # 6
7
SIDE LIGHT # 7
34
TICKET COUNTER
18
BONUS MOVING LAMP # 2
19
BONUS MOVING LAMP # 3
20
BONUS MOVING LAMP # 4
21
BONUS MOVING LAMP # 5
22
BONUS MOVING LAMP # 6
13
BONUS LIGHT # 4
14
BONUS LIGHT # 5
15
BONUS LIGHT # 6
16
BONUS LIGHT # 7
17
BONUS MOVING LAMP # 1
25
BELT SYSTEM # 1
26
BELT SYSTEM # 2
27
CRANE MOTOR
28
CRANE DIRECTION
29
BONUS ARM MOTOR
30
MONKEY LIGHT
31
STEP MOTOR
32
CRANE COIL
33
COIN COUNTER
40
COLLECTION BAR MOTOR
41
SCORE LAMP # 1
42
SCORE LAMP # 2
43
SCORE LAMP # 3
44
SCORE LAMP # 4
35
TICKET DRIVER # 1
36
TICKET DRIVER # 2
37
SCORE SEG
38
JET COLA MOTOR
39
WRENCH MOTOR
THE ABOVE OUTPUT CHART CORRESPONDS TO SOFTWARE VERSION(S) (20110413.A)
OR OLDER. ABOVE SOFTWARE WAS INSTALLED ON UNIT NUMBERS SB0110100001-
SB0110100029
45
SCORE LAMP # 5
46
SCORE LAMP # 6
47
SCORE LAMP # 7
48
SCORE LAMP # 8
NOTICE
23
BONUS MOVING LAMP # 7
24
BONUS MOVING LAMP # 8
Jennison Entertainment Technologies Space Ballz Service Manual Page 51
