MAIN BOARD OUTPUTS - (VERSION 20110730.A & NEWER)
SPACE BALLZ - MAIN BOARD OUTPUT CHART
OUTPUT #
CONTENT
OUTPUT #
CONTENT
1
SIDE LIGHT # 1
25
BELT SYSTEM # 1
5
SIDE LIGHT # 5
29
BONUS ARM MOTOR
6
SIDE LIGHT # 6
30
MONKEY LIGHT
7
SIDE LIGHT # 7
31
STEP MOTOR
2
SIDE LIGHT # 2
26
BELT SYSTEM # 2
3
SIDE LIGHT # 3
27
CRANE MOTOR
4
SIDE LIGHT # 4
28
CRANE DIRECTION
11
BONUS LIGHT # 2
35
TICKET DRIVER # 1
12
BONUS LIGHT # 3
36
TICKET DRIVER # 2
13
BONUS LIGHT # 4
37
SCORE SEG
8
SIDE LIGHT # 8
32
CRANE COIL
9
SIDE LIGHT # 9
33
COIN COUNTER
10
BONUS LIGHT # 1
34
TICKET COUNTER
17
BONUS MOVING LAMP # 1
41
SCORE LAMP # 1
18
BONUS MOVING LAMP # 2
42
SCORE LAMP # 2
19
BONUS MOVING LAMP # 3
43
SCORE LAMP # 3
14
BONUS LIGHT # 5
38
JET COLA MOTOR / WRENCH MOTOR
15
BONUS LIGHT # 6
39
COIN MECH CUTOFF
16
BONUS LIGHT # 7
40
COLLECTION BAR MOTOR
23
BONUS MOVING LAMP # 7
47
SCORE LAMP # 7
24
BONUS MOVING LAMP # 8
48
SCORE LAMP # 8
NOTICE
20
BONUS MOVING LAMP # 4
44
SCORE LAMP # 4
21
BONUS MOVING LAMP # 5
45
SCORE LAMP # 5
22
BONUS MOVING LAMP # 6
46
SCORE LAMP # 6
THE ABOVE OUTPUT CHART CORRESPONDS TO SOFTWARE VERSION(S) (20110730.A)
OR NEWER. ABOVE SOFTWARE WAS INSTALLED ON UNIT NUMBERS SB0110100030
AND ABOVE
Jennison Entertainment Technologies Space Ballz Service Manual Page 52
