8
SPARE PARTS LISTING
POS DESCRIPTION
Q
J8 Q J15 Q J25 Q J25A Q J33 Q J33A Q J50A Q J70A Q J90A Q J90SA
SP200 SP210 SP100 SP101 SP102 SP103 SP111 SP107 SP108 SP109
1 BODY/*
1
20024/A 1 20124/A 1 33206/* 1 33206/* 1 33207/* 1 33207/* 1 33284/* 1 33220/* 1 33220/* 1 33261/*
2 BOTTOM ELEC/ BOX/*
1
20019/* 1 20019/* = - = - = - = - = - = - = - 1 33445
3 COVER/*
1
20001/* 1 20101/* 1 33222/* 1 33223/* 1 33225/* 1 33226/* 1 33373/* 1 33228/* 1 33228/* 1 33262/*
4 HANDLE
1
20002 1 20002 1 33273 1 33273 1 33273 1 33273 1 33273 1 33273 1 33273 = -
5 WASHER
=
- = - = - = - = - = - 2 70200/I 2 70200/I 2 70200/I = -
6 WHEEL
=
- = - 2 33230 2 33230 2 33230 2 33230 2 33231 2 33231 2 33231 2 33265
7 HUB CAP
=
- = - 2 33230/B 2 33230/B 2 33230/B 2 33230/B 2 33230/B 2 33230/B 2 33230/B 2 33265C
8 HUB CAP COVER
=
- = - 2 33230/C 2 33230/C 2 33230/C 2 33230/C 2 33230/C 2 33230/C 2 33230/C 2 33265B
9 POL ADAPTOR / *
1
33009/* 1 33009/* 1 33009/* 1 33009/* 1 33009/* 1 33009/* 1 33009/* 1 33009/* 1 33009/* 1 33009/*
10 POL ADAPT. NUT / *
1
33010/* 1 33010/* 1 33010/* 1 33010/* 1 33010/* 1 33010/* 1 33010/* 1 33010/* 1 33010/* 1 33010/*
11 RESET BUTTON = - = - = - 1 33205 = - 1 33205 1 33205 1 33205 1 33205 1 33205
12 PRESSURE REG.
1
20009/A 1 20009/A 1 20009/A 1 20009/A 1 20009/A 1 20009/A 1 20009/A 1 20009/A 1 20009/A 1 20009/B
13 GAS SUPP. HOSE / *
1
33013/* 1 33013/* 1 33013/* 1 33013/* 1 33013/* 1 33013/* 1 33013/* 1 33013/* 1 33013/* 1 33013/*
14 NIPPLE 1\4M - 1\4M
1
33014 1 33014 1 33014 1 33014 1 33014 1 33014 1 33014 1 33014 1 33014 1 33014
15 GAS COCK
1
33244/A 1 33244/A 1 33244/A 1 33244/A 1 33244/A 1 33244/A 1 33244/A 1 33244/A 1 33244/A 1 33244/A
16 FAN SWITCH
1
33016/A 1 33124/A 1 33124/A 1 33124 1 33124/A 1 33124 1 33124 1 33124 1 33124 1 33124
17 IGNITOR
1
33017/A 1 33017/A 1 33017/A = - 1 33017/A = - = - = - = - = -
18 MAIN CABLE / *
1
33018/* 1 33018/* 1 33018/* 1 33018/* 1 33018/* 1 33018/* 1 33018/* 1 333018/* 1 33018/* 1 33018/*
19 MOTOR MOUNTING/*
=
- = - 1 33344/A 1 33357/A 1 33344/A 1 33357/A 1 33358/B 1 33358/B 1 33358/B = -
20 MOTOR/*
1
20004/* 1 20004/* 1 33108/A 1 33108/A 1 33108/A 1 33108/A 1 50006/* 1 50006/* 1 50006/* 1 33252/A
21 FAN
1
20005 1 20105 1 33110/A 1 33110/A 1 33021/A 1 33021/A 1 33427/A 1 33427/A 1 50007 1 33252/C
22 GAS RELAY VALVE
1
33245 1 33245 1 33290 = - 1 33290 = - = - = - = - = -
23 GAS PIPE
1
20132 1 20132 1 33371 1 33371 1 33370 1 33370 1 33359 1 33360 1 33361 1 33267
24 NUT 7/16 X 24
2
33088 2 33088 2 33088 2 33088 2 33088 2 33088 2 33088 2 33088 2 33088 2 33088
25 NIPPLE 7/16 X 24-1/8
2
33089 2 33089 1 33089 1 33089 1 33089 1 33089 1 33089 1 33089 1 33089 = -
26 CABLE SOL/VALVE
1
33214/C 1 33214/C 2 33214/C 2 33214/C 2 33214/C 2 33214/C 2 33214/C 2 33214/C = - = -
26 SOL/VALVE ./*
1
33214/B 1 33214/B 2 33214/B 2 33214/B 2 33214/B 2 33214/B 2 33214/B 2 33214/B 2 33214 2 33214
27 COMBUSTION/ C
1
20025 1 20125 1 33347 1 33347 1 33348 1 33348 1 33343 1 33233 1 33132 1 33285/A
28 AIR PROV. SWITCH = - = - 1 33028 1 33028 1 33028 1 33028 1 50016 1 50016 1 50016 1 33129
29 AIR PROV/SW. BR. = - = - 1 33323 1 33323 1 33323 1 33323 1 33327 1 33327 1 33327 1 33329
30 NIPPLE 1/8 - 1/8
1
33030 1 33030 2 33030 2 33030 2 33030 2 33030 2 33030 2 33030 2 33030 3 33030
31 BR.LIMIT THERM
1
20021/A 1 20021/A 1 20021/A 1 20021 1 20021/A 1 20021 1 20021 1 20021 1 20021 1 20021
32 NIPPLE 1/4-1/8
1
20030 1 20030 = - = - = - = - = - = - = - = -
33 BURNER ASSEMBLY
1
20026/A 1 20126/A 1 33215 1 33215 1 33215 1 33215 1 33369 1 33369 1 33234 1 33274
34 ELECTRODE
1
20027 1 20027 1 20027 1 33317 1 20027 1 33317 1 33317 1 33317 1 33317 1 33317
35 THERM. HOLDER
1
20015 1 20015 1 20015 = - 1 20015 = - = - = - = - = -
36 GROMMET
=
- = - 1 33368 = - 1 33368 = - = - = - = - 2 33368
37 THERMOCOUPLE
1
20010/A 1 20010/A 1 20010/A = - 1 20010/A = - = - = - = - = -
38 STOPCOCK RBS
=
- = - 1 33351 1 33351 1 33352 1 33352 1 33365 1 33366 1 33367 1 33340
