Communication with the DUPLEX Receiver via the JETIBOX:
It is possible to connect the JETIBOX in two ways:
1. Direct connection JETIBOX <-> Receiver
Plug the connector of the interconnection cable (accessory of JETIBOX) into the socket marked
Impuls + - (you will find it on the right side of the JETIBOX) and into the receiver socket marked Ext. on
the RX back side. Connect the receiver supply to the receiver directly (see Supply) or to the socket of the
JETIBOX.
2. Wireles connection JETIBOX <-> Transmitter <-> Receiver
In this case connect the JETIBOX to the transmitter.
There will appear the text Tx as well as a right and down arrow in the display. By pushing button R
(right arrow) you will enter the receiver and the display will show the text Rx, by subsequent pushing of D
(down arrow) the receiver menu will be entered, which is conform to the display shown for direct
connection (see point 1).
Wireless connection is only possible with a receiver in Normal mode. If you change mode from Normal
to Clone during the prevailing wireless connection the receiver will change to monitoring mode and the
JETIBOX will stop working. In order to restore communication with the receiver you will have to connect
the JETIBOX directly to the receiver (see point 1). If you want to use a receiver which was in the
monitoring (Clone) mode in an other model, do not forget to reset the original mode (Normal).
Disconnection of the JETIBOX is possible only after disconnection of the receiver from its power
supply. Tracking of the receiver condition or parameter setup is anytime possible, even if the
receiver is working in the model. In such a case increased caution is necessary. We do not
recommend adjustments of receiver parameters during model operation. Carry out adjustments
only if you are sure that there is no danger for the model or health of persons. For safety reasons
prevent the possibility of motor activation, it is advisable to remove the propeller from the model!
Communication with the Expander DUPLEX E8 with Aid of the JETIBOX (JB):
Plug in one plug of the connecting cable (accessory of the Expander) to the (Rx) socket on the back
side of the Expander and the other plug into the receiver socket marked (Ext.) on the receiver back side.
Connect the JETIBOX to the transmitter module. Switch on the transmitter and connect the receiver power
supply (see Supply). The JETIBOX display shows the text Tx and by pushing button R twice (arrow right)
select item Mx. By pushing the button D (down arrow) you will enter the Expander menu. The basic menu
(selection of the connected equipment Tx, Rx, Mx) you will arrive at by holding down the push button U
(upward arrow) for a longer time.
Revue of Receiver Items
The introductory display shows informations of the receiver type. By pushing button R (right arrow)
you may obtain more detailed informations about the receiver and transmitter.
Pairing: by pushing button U (upward arrow) the receiver becomes paired with the transmitter. Carry out
receiver pairing only with the JETIBOX connected directly to the receievr.
RX/TX: item RX shows the unique (production number) of the receiver. Item TX on the other hand shows
the unique (production number) of the transmitter, which the receiver has been paired with lastly.
Rx Diag: item A1 or A2 indicates, which receiver antenna is at the moment operating. Item Kx indicates
the number of transmitted channels (this number depends of the transmitter contingencies).
With the aid of push button D (down arrow) we arrive at the line of basic mode selection. Here you may
either select reading out of measured data (Measure) or receiver settings (Main setting, Channel set,
Out Pin Set, Auto Set).
