DUPLEX Rx
2
Pairing:
When using a new receiver or transmitter it is obligatory to perform the so called pairing procedure.
This is executed by inserting the shorting plug marked (BIND PLUG) into the socket at the receiver back
side (assigned to external equipment and marked Ext.) and by switching on the receiver. Subsequently
switch on the transmitter which will report pairing with the receiver by two beeps. Now remove the pairing
plug from the receiver. The transmitter is acoustically signalling presence of the pairing plug in the receiver
for the time of one minute.
Pairing can also be performed without the pairing plug (BIND PLUG) with the help of the JETIBOX. In
that case the JETIBOX must be connected directly to the receiver. Select the item (pairing) in the
JETIBOX display and push U (upward arrow). Now the receiver is waiting for switching on of the
transmitter with which it has to be paired. The transmitter again reports pairing by two beeps and
everything is ready for operation. If pairing did not succed, switch off the transmitter and receiver and
repeat the above mentioned procedure.
One transmitter may be paired with an arbitrary amount of receivers. One receiver can be paired with
one transmitter only, i. e. the receiver is paired with the transmitter which has been paired last.
Real Time Transmission of Telemetric Data:
Every receiver is already in its basic configuration able to transmit the actual voltage of the on-board
system, i. e. the receiver voltage without telemetric senzors.
One telemetric senzor can be connected directly to the socket marked (Ext.) on the receiver back
side. If connection of several senzors is necessary the expander DUPLEX Ex may be connected to the
receiver socket (Ext.).
Signalling of Bidirectional Communication Loss:
In case of bidirectional communication loss between transmitter and receiver the DUPLEX module in
the transmitter starts to indicate this situation by means of acoustic signals. This condition means that
there are no actual data available from telemetric senzors or from equipment connected to the Ext.
receiver socket input. However, the model can be further controlled even in this situation.
For receivers we grant a warranty of 24 months from the day of purchase under the assumption that
they have been operated in conformity with these instructions at recommended voltages and that they
were not damaged mechanically. Warranty and post warranty service is provided by the manufacturer.
We wish you sucessful flying with the products of : JETI model s.r.o. Pribor, www.jetimodel.com
