DIMENSIONS
STANDARD UNIVERSAL LOW EXTRA
MODEL 16 18 500 600 700 500 600 700 700 850 1050
FRAME
WIDTH A mm 453 503 600 700 800 600 700 800 800 950 1150
ins 17
5
/8 19
5
/8 23
5
/8 27
1
/2 31
1
/2 23
5
/8 27
1
/2 31
1
/2 31
1
/2 37
1
/2 45
1
/2
HEIGHT B mm 576 576 650 650 650 550 550 550 700 750 800
ins 22
5
/8 22
5
/8 25
5
/8 25
5
/8 25
5
/8 21
5
/8 21
5
/8 21
5
/8 27
1
/2 29
1
/2 31
1
/2
FIREBOX
WIDTH C mm 398 448 550 650 750 550 650 750 750 900 1100
ins 15
5
/8 17
5
/8 21
5
/8 25
5
/8 29
1
/2 21
5
/8 25
5
/8 29
1
/2 29
1
/2 35
1
/2 43
3
/8
HEIGHT D mm 549 549 630 630 630 530 530 530 680 730 780
ins 21
5
/8 21
5
/8 24
3
/4 24
3
/4 24
3
/4 20
7
/8 20
7
/8 20
7
/8 26
3
/4 28
3
/4 30
3
/4
DEPTH E mm 350 350 355 355 355 355 355 355 405 455 505
ins 13
3
/4 13
3
/4 14 14 14 14 14 14 16 18 20
OPENING REQUIRED
WIDTH mm 407 457 580 680 780 580 680 780 780 930 1130
Ins 16 18 22
7
/8 26
3
/4 30
3
/4 22
7
/8 26
3
/4 30
3
/4 30
3
/4 36
5
/8 44
1
/2
HEIGHT mm 559 559 635 635 635 535 535 535 685 735 785
ins 22 22 25 25 25 21 21 21 27 29 31
DEPTH mm 356 356 365 365 365 365 365 365 415 465 515
ins 14 14 14
3
/8 14
3
/8 14
3
/8 14
3
/8 14
3
/8 14
3
/8 16
3
/8 18
3
/8 20
3
/8
WEIGHT Kg 37 45 53 59 68 53 59 68 76 99 133
OUTPUTS / EFFICIENCY /
TEMPERATURES
WOOD TRAY with WOOD
ROOM SIZE HEATED M³ 57 70 130 150 170 70 130 150 175 200 250
HEAT OUTPUT TO ROOM
WOOD (Tested to BS3250)
KW 2.9 3.6 6.5 7.5 8.5 5.0 6.5 7.5 9.5 14.9 17
TOTAL NOMINAL HEAT OUTPUT WOOD
WHEN TESTED TO EN13229: 2001
kW 5.5 8.5 15 20 X X X X X X X
NET EFFICIENCY WOOD
TO EN13229: 2001
% 49.7 46.7 46.7 46.7 X X X X X X X
FLUE GAS TEMPERATURE
TO EN13229: 2001
°C 187 <380 <380 380 X X X X X X X
FLUE GAS MASS FLOW
TO EN13229: 2001
gs¯¹
28.9 X X 61.9 X X X X X X X
MEAN CO2 IN FLUE GAS
TO EN13229: 2001
% 2.42 X X 5.12 X X X X X X X
MEAN CO @ 13% O2
TO EN13229: 2001
% 0.35 0.35 0.35 0.17 X X X X X X X
