Jetmaster Standard 16 User Manual

DIMENSIONS
STANDARD UNIVERSAL LOW EXTRA
OUTPUTS / EFFICIENCY TEMPERATURES
BASKET with SMOKELESS FUEL
HEAT OUTPUT TO ROOM
SMOKELESS FUEL
(Tested to BS3250)
kW 2.9 3.2 5.1 5.8 6.6 4.0 5.1 5.8 6.7 10.1 12
TOTAL NOMINAL HEAT OUTPUT
SMOKELESS FUEL WHEN TESTED TO
EN13229: 2001
kW 5.9 X X X X X X X X X X
NET EFFICIENCY SMOKELESS FUEL
TO EN13229: 2001
% 52.3 X X X X X X X X X X
FLUE GAS TEMPERATURE
TO EN13229: 2001
°C 210 X X X X X X X X X X
FLUE GAS MASS FLOW
TO EN13229: 2001
gs¯¹
23.8 X X X X X X X X X X
MEAN CO2 IN FLUE GAS
TO EN13229: 2001
% 2.73 X X X X X X X X X X
MEAN CO @ 13% O2
TO EN13229: 2001
% 0.51 X X X X X X X X X X
OUTPUTS / EFFICIENCY TEMPERATURES
BASKET with WOOD
TOTAL NOMINAL HEAT OUTPUT WOOD
WHEN TESTED TO EN13229: 2001
kW 18 X X 23.4 X X X X X X X
NET EFFICIENCY WOOD
TO EN13229: 2001
% 52.6 X X 40.3 X X X X X X X
FLUE GAS TEMPERATURE
TO EN13229: 2001
°C 400 X X 375 X X X X X X X
FLUE GAS MASS FLOW
TO EN13229: 2001
gs¯¹
37.5 X X 83.8 X X X X X X X
MEAN CO2 IN FLUE GAS
TO EN13229: 2001
% 6.15 X X 4.15 X X X X X X X
MEAN CO @ 13% O2
TO EN13229: 2001
% 0.19 X X 0.18 X X X X X X X
RECOMMENDED FLUE
SQUARE mm (int.) 185 185 185 185 200 185 185 185 200 250 300
ins (int.) 7
1
/4 7
1
/4 7
1
/4 7
1
/4 8 7
1
/4 7
1
/4 7
1
/4 8 10 12
ROUND mm (int.) 180 200 200 200 200 200 200 200 225 250 300
ins (int.) 7 8 8 8 8 8 8 8 9 10 12
MINIMUM FLUE
MINIMUM FLUE ROUND mm (int.) 155 180 180 190 200 180 185 190 225 250 300
in (int.) 6 7 7 7
1
/2 8 7 7
1
/4 7
1
/2 9 10 12
MINIMUM FLUE AREA cm
2
190 250 250 285 315 250 267 285 366 507 730
in
2
30 38 38 44 50 38 42 44 57 79 113
MINIMUM FLUE DRAUGHT Pa 10 10 10 10 X 10 10 X X X X
CHIMNEY HEIGHT
ABOVE FIRE M 4.6 4.6 5.5 5.5 5.5 5.5 5.5 5.5 5.5 6.0 7.2
ft 15 15 18 18 18 18 18 18 18 20 24
AIR SUPPLY
cm
2
170 170 230 230 230 230 230 230 230 350 500
in
2
26 26 36 36 36 36 36 36 36 55 78
DIMENSIONS
STANDARD UNIVERSAL LOW EXTRA
MODEL 16 18 500 600 700 500 600 700 700 850 1050
FRAME
WIDTH A mm 453 503 600 700 800 600 700 800 800 950 1150
ins 17
5
/ 8 19
5
/ 8 23
5
/ 8 27
1
/ 2 31
1
/ 2 23
5
/ 8 27
1
/ 2 31
1
/ 2 31
1
/ 2 37
1
/ 2 45
1
/ 2
HEIGHT B mm 576 576 650 650 650 550 550 550 700 750 800
ins 22
5
/ 8 22
5
/ 8 25
5
/ 8 25
5
/ 8 25
5
/ 8 21
5
/ 8 21
5
/ 8 21
5
/ 8 27
1
/ 2 29
1
/ 2 31
1
/ 2
FIREBOX
WIDTH C mm 398 448 550 650 750 550 650 750 750 900 1100
ins 15
5
/ 8 17
5
/ 8 21
5
/ 8 25
5
/ 8 29
1
/ 2 21
5
/ 8 25
5
/ 8 29
1
/ 2 29
1
/ 2 35
1
/ 2 43
3
/ 8
HEIGHT D mm 549 549 630 630 630 530 530 530 680 730 780
ins 21
5
/ 8 21
5
/ 8 24
3
/ 4 24
3
/ 4 24
3
/ 4 20
7
/ 8 20
7
/ 8 20
7
/ 8 26
3
/ 4 28
3
/ 4 30
3
/ 4
DEPTH E mm 350 350 355 355 355 355 355 355 405 455 505
ins 13
3
/ 4 13
3
/ 4 14 14 14 14 14 14 16 18 20
OPENING REQUIRED
WIDTH mm 407 457 580 680 780 580 680 780 780 930 1130
Ins 16 18 22
7
/ 8 26
3
/ 4 30
3
/ 4 22
7
/ 8 26
3
/ 4 30
3
/ 4 30
3
/ 4 36
5
/ 8 44
1
/ 2
HEIGHT mm 559 559 635 635 635 535 535 535 685 735 785
ins 22 22 25 25 25 21 21 21 27 29 31
DEPTH mm 356 356 365 365 365 365 365 365 415 465 515
ins 14 14 14
3
/ 8 14
3
/ 8 14
3
/ 8 14
3
/ 8 14
3
/ 8 14
3
/ 8 16
3
/ 8 18
3
/ 8 20
3
/ 8
WEIGHT Kg 37 45 53 59 68 53 59 68 76 99 133
OUTPUTS / EFFICIENCY /
TEMPERATURES
WOOD TRAY with WOOD
ROOM SIZE HEATED M³ 57 70 130 150 170 70 130 150 175 200 250
HEAT OUTPUT TO ROOM
WOOD (Tested to BS3250)
KW 2.9 3.6 6.5 7.5 8.5 5.0 6.5 7.5 9.5 14.9 17
TOTAL NOMINAL HEAT OUTPUT WOOD
WHEN TESTED TO EN13229: 2001
kW 5.5 8.5 15 20 X X X X X X X
NET EFFICIENCY WOOD
TO EN13229: 2001
% 49.7 46.7 46.7 46.7 X X X X X X X
FLUE GAS TEMPERATURE
TO EN13229: 2001
°C 187 <380 <380 380 X X X X X X X
FLUE GAS MASS FLOW
TO EN13229: 2001
gs¯¹
28.9 X X 61.9 X X X X X X X
MEAN CO2 IN FLUE GAS
TO EN13229: 2001
% 2.42 X X 5.12 X X X X X X X
MEAN CO @ 13% O2
TO EN13229: 2001
% 0.35 0.35 0.35 0.17 X X X X X X X
2

Jetmaster Standard 16 Specifications

General

Brand	Jetmaster
Model	Standard 16
Category	Indoor Fireplace
Language	English
