17
4. PLACE THE CLAMP TOP OVER THE CENTER OF THE HANDLEBAR SO THAT THE 2 PRE-DRILLED HOLES IN THE CLAMP TOP ARE
ALIGNED WITH THE PRE-DRILLED HOLES IN THE CLAMP BASE.
5. FROM THE TOP, INSERT 1 BOLT INTO EACH SET OF ALIGNED HOLES UNTIL THE TIP EMERGES THROUGH THE CLAMP BASE.
6. TWIST A NUT CLOCKWISE ONTO THE END OF EACH BOLT.
HANDLEBAR CLAMP TOP
BOLTS
NUTS
HANDLEBAR CLAMP BASE
HANDLEBAR
